Network Set Up - CRC -RPM User Manual

9.
•
•
•
main screen.
token passing.
Select network Baud Rate: 9600, 19200,
38400, 57600, 76800 or
Network Setup tup
Network: BACnet
Baud Rate:
38400 38400
MAC Address:
25
Instance ID:
33321
Debug Info:
Show
Save Changes
Debug Info - Please see
Shooting / Debug Screen"
information
Room Pressure Monitor and Controller - User Guide
115,200
MAC Address: 0 – 254 MAC Address: 0 – 254
Note: MAC address must b Note: MAC address must be unique for each device
on a specific MS/TP trunk on a specific MS/TP trunk
Don't Show
Exit -No Change ge
"BACnet Trouble
for more
13
Instance ID: 1 – 4,194,304
Note: Instance ID must be unique for
each device on the overall network
Debug Info: Displays Network information
on main screen to assist in debugging
network related issues
© 2012 CRITICAL ROOM CONTROL
