8 Ports Ethernet Switch
User Manual
8 ports Ethernet Switch is an unmanaged Ethernet switch. This product provides 1 Gigabit uplink Ethernet
port and 1 Gigabit uplink fiber port and 8* 100Mbps Ethernet ports. The product is widely used in video
surveillance and network program.
Application
IP camera
Dome camera
IP camera
Dome Camera
Feature
Support IEEE802.3,IEEE802.3u, IEEE802.3ab, IEEE802.3z
Provide 1*
1000Mbps
uplink fiber port and
ports;
Reset button of 8
PoE
ports which can easily solve
network cable, is very convenient for system maintenance;
Under one Key CCTV model, the 1~8 downlink ports can only communicate with uplink ports, the
downlink port is limited in 10Mbps
and the transmission distance is up to 250m
One Key CCTV mode
is off by default
, but can start while dialing the switch key on the front board to reset
the product;
1 M packet data cache to ensure large capacity data transfer
8K MAC address, easy for network system expansion;
Support IEEE802.3X full duplex data control; support port (Auto MDI/MDIX) function ;
Redundant power design, support power hot backup;
Industrial product,
fanless wavy metal shell design for good heat dissipation;
Excellent isolated circuit protection, lighting protection up to 6KV;
Fast
Installation ,
easily
operation, so as to be convenient for wall, din rail and desktop installation.
1
standards
;
1*1000Mbps
Ethernet port, 8*
10/100Mbps
downlink Ethernet
problems of
IP camera crash, without plugging
;
smoothly
;
Caution
1) Transmission distance is related to the connecting cable. We suggest to use standard Cat5e/6
VerB 1.1
network cable to get the best transmission result.
2) If use optical uplink port, customer needs to purchase
3) The equipment must be connected to anti-thunder grounding ,otherwise the
greatly reduced ; please use NO. 20th or above wire to connect grounding terminal to the earth.
Board Diagram
Front Board
SFP
optical port
Power/Uplink optical
port/CCTV indicator light
Back Board
Description:
speed of
1) Front board with Ethernet port, the green light is to indicate network status; the yellow light and green
light on the uplink network RJ 45 socket is to indicate network working status; the LED on the
of
SFP optical port is to indicate power, CCTV and working status of
2) The left board and back board have a DC12V~24V power input port respectively;
Installation steps
Please check the following items before installation. If any missing, please contact the dealer.
Ethernet switch
Power adapter
MIT hangers
Din rail hanger
User manual
8 Port Ethernet Switch
additional
Left Board
Ethernet port
Uplink port
Up Board
Ground terminal
Power input
1 pc
1 pc
2 pc
1 pc
1 pc
SFP module.
protection level
will be
Power input
CCTV Mode
left side
optical port
;
2
