HELGI HI0378A User Manual

HDBitT HDMI over Fiber Optic Extender
Important safety notice
Please read below safety instructions carefully before installation and operation:
Please pay attention to all the warnings and hints on this device.

Do not expose this unit to rain, moisture and liquid.

Do not put any stuff into the device.

Do not repair or open this device without professional people's guidance.

Make sure good ventilation openings to avoid product overheating damage.

Shut off power and make sure environment is safe before installation.

Do not plug-in/out the network cables and IR cables when it is in using to avoid cables

damage.
Use DC5V only. Make sure the specification matched if using 3


1 Introduction

This HDMI over fiber optic incorporates HDBitT transport technology, allowing you to extend
20KM distance between the source device to display end and supporting IR pass back function. It
can be widely applied in video conference, medical system, shopping mall, multimedia
presentation etc filed.

2 Features

1. Single mode fiber optic transmission.
2. No need extra installation driver
3. Transmit 1080p signal up to 20KM
4. Support IR pas back for easy control
5. Avoid the electromagnetic interference in environment for long distance transmission
6. Low signal loss, wide frequency band and strong anti-interference
7. High-end aluminum alloy enclosure design
8. Wall-mountable design for convenient installation
User Manual
party DC adapters.
rd
