Page 2: Product Introduction
Thank you for purchasing this product. For optimum performance and safety, please read the instructions carefully and keep the manual for future reference. • Important Safety Notice Please read below safety instructions carefully before installation and operation: 1. Do not mix up the transmitter unit (TX) and the receiver unit (RX) before installation. -
Page 3: Installation Requirements
• Package Contents • Installation Requirements 1. HDMI source device(computer graphics card, DVD, PS3, HD monitoring equipment etc). 2. HDMI display device like SDTV, HDTV, projector with HDMI port. 3. UTP/STP CAT6/6A/7 cable, follow standard IEEE-568B. • Penal Description 1. Transmitter unit(TX) - Page 4 2. Receiver unit (RX) Remarks: Users can press button”Length”to adjust transmittion distance of this device automatically or manually. If users do not press this button when power on, then the device will work like last time because of memory function. If users press this button after power, on the first two press will make the device adjust the distance according to the network cable length automatically.
- Page 5 2.Connection 3. Connection instruction 1 ) Plug the transmitter unit (TX) to the HDMI output port of the source device directly, and plug the receiver (RX) to the HDMI input port of the display device directly. 2 ) Connect Transmitter unit (TX) and Receiver unit (RX) via network cables (CAT6,CAT6A or CAT7).
- Page 6 · Specification Disclaimer The product name and brand name may be registered trademark of related manufacturers. TM and ® may be omitted on the user manual. The pictures on the user manual are just for reference, and there may be some slight difference with the real products.
