Advantech FWA-3240 Startup Manual

FWA-3240 1U Rackmount Intel® Tolapai-based Plat-
form with 4 Front LAN Ports & LCD Display
Startup Manual

Packing List

Before installation, ensure that the following materials have
been received:
• One FWA-3240 Internet Security Platform
• One box of accessories
• One warranty certificate
If any of these items are missing or damaged, please con-
tact your distributor or sales representative immediately.
Note:
Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at: www.
adobe.com/Products/acrobat/readstep2. html
(Acrobat is a trademark of Adobe)

Safety Instructions

1. Do not leave this equipment in an environment un-
conditioned where the storage temperature under 0°
C (32° F) or above 40° C (104° F), it may damage the
equipment.
2. The openings on the enclosure are for air convection
hence protect the equipment from overheating. DO NOT
COVER THE OPENINGS.
3. Make sure the voltage of the power source is correct
before connecting the equipment to the power outlet.
4. Place the power cord in a way that people can not
step on it. Do not place anything over the power cord.
The voltage and current rating of the cord should be
greater than the voltage and current rating marked on
the product.
If you have any technical questions about the FWA-
3240 or any other Advantech products, please visit our
support website at:
http://www.advantech.com.tw/support
http://www.advantech.com.
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the FWA-3240 series Rev. A
Part No. 2002324000
Print in China

Specifications

Standard SBC functions
• CPU & Chipset: Intel EP80579 Integrated Processor
(Tolapai) supports 600/1066/1200 MHz processor
• BIOS: Award™ 4Mbit Flash
• FSB: 400/533 MHz
• System memory: Up to 2GB memory capacity. One
DIMM socket supporting DDR2 SODIMM technology
memory. 200-pin DDR2-533, DDR2-667 and DDR2-800
can be used.
Note:
• CF Interface: JMicron (SATA to IDE bridge)
1 x CF socket on IDE 0 (Primary)
• SATA Interface: 1 x 2.5" or 3.5" HDD bay Max. data
transfer rate at 150 MB/sec.
• Keyboard/mouse Pin header: Supports standard PS/2
keyboard and mouse for debug and installation use.
• USB 2.0: 2 x USB 2.0
• Serial: 1 x RS-232 with RJ-45 connector
Ethernet interface
• Interface: 4 x 10/100/1000 Base-T
• Controller: Three GbE from Intel EP80579 Integrated
Processor + Marvell 88E1111 PHY, One GbE from Intel
82574, with bypass function
Mechanical and Enviromental
• Dimensions(W x H x D): 426 x 44 x 236 mm (16.8" x
1.7" x 9.3")
• Power supply voltage: 180 W, 90 ~ 240V AC, auto range
• Operating temperature: 0 ~ 40°C (32 ~ 104°F)
• Weight: 4.2kg (9.3lb)
1st Edition,
Nov 2008
Due to the inherent limitations of PC architecture,
the system may not fully detect 4 GB RAM when
4 GB RAM is installed.
FWA-3240 Startup Manual
