Migatronic RALLY MIG 161i Quick Manual

RALLY MIG 161i - Factory setting
Setting possibilities Area
Primary parameters:
1 Welding current Area depends on
program
Wire feed speed
Thickness of material
2 Arc length -9.9 – +9.9
Secondary parameters:
1 Hotstart (MMA/TIG) 0 - 100
3 Arc power (MMA/TIG) 0 - 150
TIG process (TIG) ON/OFF
1 Arc Adjust (MIG) -5.0 – +5.0
6 Burnback (MIG) 1 – 30
MIG parameters
Set welding current (A)
Burnback
Arc adjust (electronic choke)
1
Step Factory setting Unit
2T
1 Depending on A
program
0.1 m/min
0.1 mm
0.1 0.0 V
1 25 %
1 25 %
OFF
0.1 0.0 -
1 5 ms
MMA parameters
TIG
welding
Arc
power
Hotstart
Short circuit
Set welding
current (A)
50113775 D
QUICKGUIDE RALLY MIG 161i
Programs
No. Wire Material
P106 Ø 0.6 mm Fe SG2
P101 Ø 0.8 mm Fe SG2
P109 Ø 0.9 mm Fe SG2
P102 Ø 1.0 mm Fe SG2
P116 Ø 0.6 mm Fe SG2
P111 Ø 0.8 mm Fe SG2
P119 Ø 0.9 mm Fe SG2
P112 Ø 1.0 mm Fe SG2
P201 Ø 0.8 mm CrNi ER 316 LSI
P209 Ø 0.9 mm CrNi ER 316 LSI
P202 Ø 1.0 mm CrNi ER 316 LSI
P311 Ø 0.8 mm AlMg5 ER5356
P319 Ø 0.9 mm AlMg5 ER5356
P312 Ø 1.0 mm AlMg ER5356/ER5554
P359 Ø 0.9 mm AlSi5 ER4043
P352 Ø 1.0 mm AlSi5 ER4043
P369 Ø 0.9 mm AlMg3Mn ER5554
P372 Ø 1.0 mm AlSi12 ER4047
P501 Ø 0.8 mm CuAl8 Brazing
P509 Ø 0.9 mm CuAl8 Brazing
P502 Ø 1.0 mm CuAl8 Brazing
P561 Ø 0.8 mm CuSi3 Brazing
P569 Ø 0.9 mm CuSi3 Brazing
P562 Ø 1.0 mm CuSi3 Brazing
Note: Fe programs with reversed polarity are recommended
for Innershield wires
UK
Gas
CO
2
CO
2
CO
2
CO
2
ArCO (82/18)
2
ArCO (82/18)
2
ArCO (82/18)
2
ArCO (82/18)
2
ArCO (98/2)
2
ArCO (98/2)
2
ArCO (98/2)
2
Ar
Ar
Ar (100)
Ar (100)
Ar
Ar (100)
Ar (100)
ArCO (98/2)
2
ArCO (98/2)
2
ArCO (98/2)
2
ArCO (98/2)
2
Ar (100)
ArCO (98/2)
2
