DISPLAY & FUNCTIONS
Before using the functions of the handlebar mounted display,
the main power to the bike must be turned on.
Please locate the power key switch located on the left side top of the battery.
You must turn the key to the on position and keep key locked into bike.
To turn off main power simply turn the key to the off position and remove key.
There is also a locked position which can be used to keep battery securely locked
onto your ebike while power is off. You can remove key in this position.

BUTTONS

'ON/OFF' : Powers ebike ON/OFF
S S S 'S + ' : Pedal assistance level up
+ +
– –
S S S S S S S S
'S -' : Pedal assistance level down
C
'C' : light switch
S S S
+ +
C
– –
S S S S S S S S
Electric system display and control unit
6
iGO
POWER
ASSIST
w w w . i g o e l e c t r i c . c o m
MAX AVG
+ –
ODO TRIP VOL CUR
MPH
Km/h
ECU
T1
MILE
Km
