- Page 1 USE AND MAINTENANCE MANUAL FS700 B FS800 B ED. 11-2012 ORIGINAL INSTRUCTIONS Doc. 10032018 Version...
- Page 2 The descriptions contained in this document are not binding. The company therefore reserves the right to make any modifications at any time to elements, details, or accessory supply, as considered necessary for reasons of improvement or manufacturing/commercial requirements. The reproduction, even partial, of the text and drawings contained in this document is prohibited by law.
-
Page 3: Table Of Contents
7 FOOTBOARD FRONT-LEFT COMPONENTS ..............................8 FOOTBOARD REAR COMPONENTS ................................9 SIDE COMPONENTS OF THE MACHINE ..............................10 REAR COMPONENTS OF THE MACHINE (FS700 B) ........................... 11 FRONT MACHINE COMPONENTS................................12 TYPE OF BATTERY....................................13 BATTERY MAINTENANCE AND DISPOSAL .............................. - Page 4 39 ELECTRIC FUSES AND THERMAL CUT-OUTS ............................40 THE MACHINE DOES NOT CLEAN WELL ..............................41 THE MACHINE LIFTS DUST DURING OPERATION ............................. 42 EXCESSIVE OR ALTERED NOISE OF THE CENTRAL BRUSH........................43 EXCESSIVE OR ALTERED NOISE OF THE SIDE BRUSH ..........................DISPOSAL........................................
-
Page 5: On Consignment Of The Machine
The machine must operate on dry surfaces, and if necessary can also work on wet surfaces making sure the vacuum action is not active. TECHNICAL DESCRIPTION FS700 B FS800 B FS800 B (Basic) Working width without side brush... -
Page 6: Symbols Used On The Machine
SYMBOLS USED ON THE MACHINE Main switch symbol (key switch) Used on the instrument panel, to indicate the key switch for machine operation on (I) or off (O) Symbol denoting battery electric charging Symbol denoting vacuum motor Used on the instrument panel to indicate the green three-way switch, showing that the left-hand vacuum motor is in operation Filter shaker symbol Used on the instrument panel to indicate the green three-way switch, showing that the filter shaker in the panel filter unit is in operation... - Page 7 SYMBOLS USED ON THE MACHINE Symbol denoting treading ban Used to indicate the area of the machine on which it is forbidden to tread or stand Central/side brush(es) motion symbol (idle position) Used to indicate the movement linkage of the central/side brush(es) Central/side brush(es) motion symbol (working position) Used to indicate the movement linkage of the central/side brush(es) Indicates the maximum gradient...
-
Page 8: General Safety Regulations
GENERAL SAFETY REGULATIONS The regulations below must be carefully followed in order to avoid harm to the operator and damage to the machine. WARNING: • Read the labels on the machine carefully. Do not cover them for any reason and replace them immediately if they become damaged. •... -
Page 9: Machine Preparation
The total mass of the machine with packaging is 350 kg (FS800 version without batteries) The total mass of the machine with packaging is 335 kg (FS800 Basic version without batteries) The dimensions of the packaging is as follows: FS700 B – FS800 B – FS800 Basic A: 1620mm B: 1280mm C: 2040mm 2. -
Page 10: Steering Column Components
MACHINE PREPARATION Three-way selector debris hopper lift-descent control: • front position debris hopper in lifting phase • intermediate position debris hopper movement not active • rear position debris hopper in descent phase Three-way selector debris hopper rotation control: • front position debris hopper tilting, for emptying •... -
Page 11: Side Components Of The Machine
The side components of the machine are identified as follows: 14. Blinking light (optional) 15. Rear casing lifting handle 16. Storage compartment casing 10. REAR COMPONENTS OF THE MACHINE (FS700 B) The rear components of the machine are identified as follows: 17. Rear casing retainer 18. Debris hopper handle 19. -
Page 12: Fitting The Batteries Into The Machine
MACHINE PREPARATION WARNING: You are advised to always wear protective gloves, to avoid the risk of serious injury to your hands. WARNING: You are advised to only lift and move the batteries with lifting and transportation means suitable for the specific weight and size 14. -
Page 13: Battery Connection And Battery Connectors
MACHINE PREPARATION 15. BATTERY CONNECTION AND BATTERY CONNECTORS 1. Connect the batteries in series - using the jumper cables supplied (3) - to the poles “+” and “-“ 2. Connect the battery connector cable (1) to the terminal poles “+” and “-“ to obtain a voltage of 24V on the clamps 3. -
Page 14: Battery Charger Connection (Versions With Bc)
MACHINE PREPARATION ATTENTION: Danger of exhalation of gas and leakage of corrosive liquids. ATTENTION: Danger of fire: do not go near with free flames 17. BATTERY CHARGER CONNECTION (VERSIONS WITH BC) In order not to cause permanent damage to the batteries it is essential to avoid their complete discharge: arrange the recharge within a few minutes of the switching on of the flashing "discharged batteries"... -
Page 15: Battery Charge Level Indicator
MACHINE PREPARATION ATTENTION: Never leave the batteries completely discharged, even if the machine is not being used. ATTENTION: For the daily recharging of the batteries, you must fully respect the indications provided by the manufacturer or retailer. All installation and maintenance operations must be carried out by specialised personnel. -
Page 16: Side Brush Assembly
MACHINE PREPARATION 21. SIDE BRUSH ASSEMBLY Check that the parking brake is engaged, if not engage it. Make sure that the main switch is in the 0/OFF position, if not turn the key a quarter turn to the left. Lift the side brush arm by turning the right lever (1) anticlockwise. WARNING: During this operation, check there are no people or objects near the brush. -
Page 17: Work
WORK 24. PREPARING TO WORK Check that the debris hopper is empty; if not, empty it completely Check that the debris hopper is in the working position, otherwise position it correctly Check that the parking brake is engaged, if not engage it Make sure that the main switch is in the "0/OFF"... -
Page 18: Emptying The Debris Hopper (Manual Movement)
WORK Press the front flap-raiser pedal (8) when working with bulky waste, to allow the central brush to reach and collect it. WARNING! Do not hold the pedal for long. In order to achieve a correct vacuum action, clean the filter every 10 minutes and always before any discharge of the debris hopper. -
Page 19: Emptying The Debris Hopper (Manual Movement)
WORK WARNING! Do not keep the switch (3) pressed longer than ten seconds, repeat this operation two or three times. WARNING: Before performing any maintenance, remove the keys from the panel and disconnect the battery connector of the machine. 6. Release the hinge (4) on the back of the machine. 7. - Page 20 WORK 5. Disengage the parking brake 6. Bring the machine close to the waste container which has been prepared for unloading 7. Stop the machine and engage the parking brake WARNING! Calculate the distance between the machine and the waste container correctly, bearing in mind the rotation radius of the debris hopper when moving.
-
Page 21: At The End Of The Work
AT THE END OF THE WORK AT THE END OF THE WORK (VERSIONS WITH MANUAL EMPTYING OF THE DEBRIS HOPPER) At the end of the work, and before carrying out any type of maintenance, perform the following operations: 1. Bring the machine to the place provided for its draining 2. -
Page 22: At The End Of The Work (Versions With Automatic Emptying Of The Debris Hopper)
AT THE END OF THE WORK 28. AT THE END OF THE WORK (VERSIONS WITH AUTOMATIC EMPTYING OF THE DEBRIS HOPPER) At the end of the work, and before carrying out any type of maintenance, perform the following operations: 1. Bring the machine to the place provided for its draining 2. - Page 23 AT THE END OF THE WORK 18. Move the switches (4) and (5) backward, until the debris hopper has returned to the working position WARNING! If the debris hopper is not in the correct position the machine will not work to its full potential.
-
Page 24: Daily Maintenance
DAILY MAINTENANCE PERFORM ALL MAINTENANCE OPERATIONS IN SEQUENCE 29. CLEANING THE CENTRAL BRUSH Proceed as follows in order to clean the central brush: 1. Engage the parking brake. 2. Make sure that the main switch is in the "0/OFF" position, if not turn the key a quarter turn to the left. -
Page 25: Cleaning The Side Brush
DAILY MAINTENANCE 13. Reassemble all the elements. ATTENTION: The brush is correctly fitted when, seen from above, the cusp forms an upturned “V” (refer to the picture) 30. CLEANING THE SIDE BRUSH Proceed as follows in order to clean the side brush: 1. -
Page 26: Weekly Maintenance
WEEKLY MAINTENANCE 31. CLEANING THE PANEL FILTER (FP VERSIONS) Whenever the vacuum action seems to be unsatisfactory, check that the vacuum filter is not obstructed. If necessary clean with an air jet as follows: 1. Engage the parking brake. 2. Make sure that the main switch is in the "0/OFF" position, if not turn the key a quarter turn to the left. -
Page 27: Cleaning The Cloth Filter (Fs Versions)
WEEKLY MAINTENANCE 32. CLEANING THE CLOTH FILTER (FS versions) Whenever the vacuum action seems to be unsatisfactory, check that the vacuum filter is not obstructed. If necessary clean with an air jet as follows: 1. Engage the parking brake. 2. Make sure that the main switch is in the "0/OFF" position, if not turn the key a quarter turn to the left. -
Page 28: Cleaning The Debris Hopper (Versions With Manual Emptying Of The Debris Hopper)
WEEKLY MAINTENANCE 33. CLEANING THE DEBRIS HOPPER (VERSIONS WITH MANUAL EMPTYING OF THE DEBRIS HOPPER) Clean the debris hopper every week as follows: 1. Engage the parking brake. 2. Make sure that the main switch is in the "0/OFF" position, if not turn the key a quarter turn to the left. -
Page 29: Side Brush Adjustment
WEEKLY MAINTENANCE 35. SIDE BRUSH ADJUSTMENT If the side brush does not channel the dirt efficiently towards the centre of the machine, you must adjust its height in relation to the ground, as follows: 1. Engage the parking brake. 2. Make sure that the main switch is in the "0/OFF" position, if not turn the key a quarter turn to the left. - Page 30 WEEKLY MAINTENANCE 9. Fix the counter nut (5) by using the right equipment. ATTENTION: This operation must be carried out using gloves to protect against contact with dangerous substances. 10. By using the right equipment, assemble the side brush casing (4), fixing the screws (3) ATTENTION: This operation must be carried out using gloves to protect against contact with dangerous substances.
-
Page 31: Extraordinary Maintenance
EXTRAORDINARY MAINTENANCE 36. CENTRAL BRUSH REPLACEMENT If the central brush is worn, this will affect its performance. Proceed as follows to replace: 1. Engage the parking brake. 2. Make sure that the main switch is in the "0/OFF" position, if not turn the key a quarter turn to the left. -
Page 32: Central Brush Replacement
EXTRAORDINARY MAINTENANCE 37. CENTRAL BRUSH REPLACEMENT If the central brush is worn, this will affect its performance. Proceed as follows to replace: 1. Engage the parking brake. 2. Make sure that the main switch is in the "0/OFF" position, if not turn the key a quarter turn to the left. -
Page 33: Troubleshooting
TROUBLESHOOTING 38. THE MACHINE DOES NOT START Check the connector is connected to the batteries Check the key switch is ON/I Check that batteries are charged 39. ELECTRIC FUSES AND THERMAL CUT-OUTS In addition to general 80 A fuses, the machine is also fitted with self-restoring safety fuses located on the boards in the electric system that interrupt the power supply to the brush and vacuum motor when the machine exceeds the predetermined load. -
Page 34: Disposal
DISPOSAL To dispose of the machine, take it to a demolition centre or an authorised collection centre. Before scrapping the machine it is necessary to remove and separate the following materials and send them to the appropriate collection centres in accordance with the environmental hygiene regulations currently in force: •... -
Page 35: Choosing And Using The Brushes
1.1 + 0.7 Central brush 435164 PPL + Bronze Central brush, white 435165 PPL + Bronze Central brush, black FS700 B 1SL 435166 PPL + Steel Central brush, black 435433 Side brush, black 435432 PPL + Steel 1.1 + 0.7... -
Page 36: Ec Declaration Of Conformity
Santa Maria di Zevio (VR), 08/11/2011 FIMAP S.p.A. Legal representative Giancarlo Ruffo FIMAP spa Via Invalidi del Lavoro, 1 - 37050 S.Maria di Zevio (Verona) Italy Tel. +39 045 6060411 r.a. - Fax +39 045 6060417 - E-mail:fimap@fimap.com - www.fimap.com... -
Page 37: Ec Declaration Of Conformity
Santa Maria di Zevio (VR), 08/11/2011 FIMAP S.p.A. Legal representative Giancarlo Ruffo FIMAP spa Via Invalidi del Lavoro, 1 - 37050 S.Maria di Zevio (Verona) Italy Tel. +39 045 6060411 r.a. - Fax +39 045 6060417 - E-mail:fimap@fimap.com - www.fimap.com... - Page 38 FIMAP spa Via Invalidi del Lavoro, 1 - 37050 S.Maria di Zevio (Verona) Italy Tel. +39 045 6060411 r.a. - Fax +39 045 6060417 - E-mail:fimap@fimap.com - www.fimap.com...
- Page 39 FIMAP spa Via Invalidi del Lavoro, 1 - 37050 S.Maria di Zevio (Verona) Italy Tel. +39 045 6060411 r.a. - Fax +39 045 6060417 - E-mail:fimap@fimap.com - www.fimap.com...
- Page 40 FIMAP spa Via Invalidi del Lavoro, 1 - 37050 S.Maria di Zevio (Verona) Italy Tel. +39 045 6060411 r.a. - Fax +39 045 6060417 - E-mail:fimap@fimap.com - www.fimap.com...
