Page 2
A typical signal source for the line-level inputs of the Peavey PBK15BT would be a sound reinforcement mixing console (mixer) or the output from a CD player, MP3 player or tape deck. A dynamic microphone can be connected to the Mic Input and used...
VALUE IN ORDER TO AVOID DAMAGE TO THE EQUIPMENT AND TO PREVENT VOIDING THE WARRANTY! The fuse in the Peavey PBK15BT can be replaced with a time- delay type 5 x 20 mm size 250V rated fuse. For 110-120VAC operation, a fuse rated at 3.15 amps and 250V should be used, which conforms to the international fuse classification "T3.15A".
Page 4
LINE OUT jacks (7) These jacks are intended for the use of linking multiple PBK15BT in a line or to provide a feed to a powered subwoofer, or other electronics that needs to receive a full range version of the input signal. The connectors available are a male XLR jack, and a 1 / 4"...
Page 5
Output Connections: One male XLR and one 1/4" phone jack. The Line Out jacks are intended for the use of linking multiple PBK15BT in a line or to provide a feed to a powered subwoofer, or other electronics that needs to receive a full range version of the input signal.
Page 9
Warranty registration and information for U.S. customers available online at www.peavey.com/warranty or use the QR tag below Features and speci cations subject to change without notice. Peavey Electronics Corporation 5022 Hartley Peavey Drive Meridian, MS 39305 (601) 483-5365 FAX (601) 486-1278 Logo referenced in Directive 2002/96/EC Annex IV (OJ(L)37/38,13.02.03 and defined in EN 50419: 2005...
