Summary of Contents for Peavey TRANSTUBE Series
- Page 1 PATENTS APPLIED FOH...
- Page 2 Intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. Intended to alert the user of the presence of important operating and maintenance (servicing) instructions in the literature accompanying the product.
- Page 3 Congratulations on your purchase of the all new Studio Pro@ 112 TransTubeTM Series. This amp represents years of research on vacuum tube emulation, resulting in a totally new Studio Pro. The preamp has been redesigned, using patent-applied for technology that redefines tubelike distortion and harmonic generation in solid-state amps.
- Page 4 GAIN SWITCH (9) Boosts the overall system gain. Depress to the “in” position to activate. LOW, MID, & HIGH EQ (10) Passive tone controls that regulate the low, mid, and high frequencies, respectively. POST GAIN (11) Controls the overall volume level of the Lead channel. The final level adjustment should be made after the desired sound has been achieved.
-
Page 5: Specifications
Effects Return: Mid @ 0 SPECIFICATIONS Pre & Post Gain @ 10 Impedance: High Z, 22 K ohms Gain & Thrash, Off (Out) Designed Input Level: -10 dBV, Normal Levels are with normal 0.3 V RMS Rated Power & Load: volume @ 5 (Switching jack provides Effects 65 W RMS into 8 ohms... -
Page 6: Tone Settings
TONE SETTINGS ADJUST TO “IN” TASTE CLEAN METAL “OUT” “OUT” “OUT” ADJUST TO TASTE JAZZ MEDIUM DISTORTION “OUT” “OUT” “OUT” CLEAN DIRTY BLUES BLUES T E C H N O L O G Y PATENTS APPLIED FOR... - Page 7 Consulte 10s diagramas de1 panel delantero en la seccih de inglks de este manual. HIGH GAIN INPUT (Entrada de ganancia alta) (1) Se usa para la mayoria de las guitarras electricas. Tiene 6 dB mas volumen que la entrada de baja ganancia. LOW GAIN INPUT (Entrada de baja ganancia) (2) Se suministra para instrumentos que tienen una salida extremadamente alta, la cual puede causar la sobrecarga mismo (ambos son de baja ganancia).
- Page 8 Oprima el interruptor a la position “hacia dentro” (encendido). La luz roja de1 pilot0 (indicador) se encendera indicando que la unidad esta recibiendo corriente alterna. PRODUCT OF PEAVEY ELECTRONICS COW MADE IN U S A. LINE CORD (120 V PRODUCTS ONLY) (Cable de corriente para 120 v solamente) (17) peligrosos corrientazos.
- Page 9 Veuillez vous r6f6rer au “front panel line art” situ6 dans la section en langue anglaise de ce manuel. HIGH GAIN INPUT (Entree haut gain) (1) Cette prise s’utilise avec la plupart des guitares electriques. Elle donne un gain superieur de 6 dB a l’entree “Low Gain”.
- Page 10 POWER LED (DEL temoin de mise sous tension) (15) S’allume lorsque l’ampli recoit l’alimentation CA. POWER SWITCH (Interrupteur d’alimentation) (16) Mettre l’interrupteur en position “On”. La lampe temoin rouge (DEL) s’illumine indiquant que l’appareil est A PRODUCT OF PEAVEY ELECSRONlCS EXTERNAL SPEAKER REMOTE PATENT PENDING SWITCH LINE CORD (120 V products only) (Cordon d’alimentation pour appareils 120 V seulement) (17)
- Page 11 Siehe Diagramm der Frontplatte im englischen Teil des Handbuchs. HIGH GAIN INPUT (1) Dieser Eingang kann fur die meisten elektrischen Gitarren verwendet werden. Er ist 6 dB empfindlicher als der Low Gain Input. LOW GAIN INPUT (2) Dieser Eingang ist fur die Instrumente vorgesehen, die ein besonders hohes Ausgangssignal erzeugen. Falls beide VOLUME (3) Regelt den Pegel des “Clean”-Kanals.
- Page 12 POWER LED (15) Zeigt die eingeschaltete Netzspannung an. POWER SWITCH (Netzschalter) (16) eingeschaltet ist. LINE CORD (120 V products only) (Nur bei 120 Volt-Gertiten) (17) Zu lhrer Sicherheit haben wir das Gerat mit einem dreiadrigen geerdeten Netzkabel versehen. Es ist unter keinen Umstanden empfehlenswert den Erdungskontakt des Anschlufikabels zu losen.
- Page 13 For further information on other Peavey products, ask your Authorized Peavey Dealer for the appropriate Peavey catalog/publication: Bass Guitars Guitars Bass Amplification Guitar Amplification Sound Reinforcement Enclosures Microphones Keyboards Lighting Mixers, Powered/Non-Powered Accessories/Cables Effects Processors The Peavey BeatTM Monitor@ Magazine...
- Page 14 PEAVEY go-DAY LIMITED WARRANTY ON TUBES AND METERS If this product contains tubes or meters, Peavey warrants the tubes or meters contained in the product to be free from defects in material and workmanshlp for a penod of ninety (90) days from date of purchase; PROVIDED, however, that this limited warranty is extended only to the original retail purchaser and is also subject to the conditions, exclusions, and limitations heretnafter set forth.
- Page 15 The user should not attempt to service this equipment. All service work should be done by a qualified service technician. This product should be used only with a cart or stand that is recommended by Peavey Electronics. Exposure to extremely high noise levels may cause a permanent hearing loss. Individuals vary considerably in susceptibility to noise induced hearing loss, but nearly everyone will lose some hearing if exposed to sufficiently intense noise for a sufficient time.
- Page 16 Features and specifications subject to change without notice. Peavey Electronics Corporation 711 A Street / Meridian, MS 39301 / U.S.A. / (601) 483-5365 / Fax 486-l 278 01995 Printed in U.S.A. 6/95...
