Fix Ears ( Option )

4.) Setting up your Device

Before we Start

*Before setting up the device make sure of the following:
1.) All the package contents are all included if anything is missing please
contact the dealer where the device was purchased from.
2.) Check that the power input cable is working correctly.
3.) Check the cables to make sure there are no problems with the cable.

Setup for Internet Access

To access the 9258xx from the internet, the router will require port forwarding to
be activated for your IP Power device.
* Please refer to your routers manual on how to port forward the device.
For example
9258xx IP Address: 192.168.100.200
Port: 8080
* On the router you will need to port forward both TCP / UDP to the IP Address
192.168.100.200 on Port 8080.
User can fix 9258xx on with screws and ear.Notice: The
fixed screws SPEC is type M3 and the length of the
screw do not over 5mm.
- 10-
