IP POWER 9258-1U USER MANUAL
IP POWER 9258-1U
USER MANUAL

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IP POWER 9258-1U and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Aviosys IP POWER 9258-1U

Summary of Contents for Aviosys IP POWER 9258-1U

  • Page 1 IP POWER 9258-1U USER MANUAL IP POWER 9258-1U USER MANUAL...
  • Page 2 IP POWER 9258-1U USER MANUAL USER MANUAL IP POWER 9258-1U Version: V1.50 2008.05 - 1 - VER1.50...
  • Page 3 IP POWER 1U USER MANUAL Warning: Any changes to this equipment without permission may cause damages to your equipment! This equipment has been proved by CE & FCC to can be prevented from the influence of harmful electronic jamming in normal business use condition.

  • Page 4: Table Of Contents

    IP POWER 9258-1U USER MANUAL Table of Con tent 1. INTRODUCTION ......................4 ......................... FEATURES IP P 9258-1U ................. OWER FUNCTION DESCRIBE 2.SPECIFICATION ......................5 ......................PACKAGE ONTENTS ..................MINIMUM YSTEM EQUIREMENTS 3.INTERFACE DESCRIPTION..................6 4.HARDWARE & SOFTWARE INSTALLATION ............8 ....................

  • Page 5: Introduction

    IP POWER 1U USER MANUAL 1. Introduction The Standard 1U 19” Rack mount, IP POWER 9258-1U is a web controller which can be easily used in the industry field. With the remote network control technology, user can control or query the power supply of equipment.

  • Page 6: Specification

    IP POWER 9258-1U USER MANUAL 2. Specification Package contents One set of IP Power 9258-1U Front : Back Panel: * 9258T-1U Version : * 9258S-1U Version : Option : RJ45 (Cat5) net wire Option : Input Power Cable : Style Pan European , Australia or United Kingdom...

  • Page 7: Interface Description

    IP POWER 1U USER MANUAL 3. Interface Description There are 2 model of IP Power 9258-1U, please refer the outlook of each model as follow: Model & outlet style: Brazil, 中国, Canada, 日本, Mexico, Philippine, 台灣, Thailand, USA. IP Power 9258S -1U:...
  • Page 8 IP POWER 9258-1U USER MANUAL IP Power 1U : all four series apply same main device. * Front panel show as below: From left to the right: 1. Power 1: Power switch (RED) for outlet 1- 4 switch ON /OFF and Self-protect AC reset button to cut off the power supply of outlets automatically if there is a shortcut or current overload.

  • Page 9: Hardware & Software Installation

    IP POWER 1U USER MANUAL 4. Hardware & Software installation Before you star to use IP Power 9258-1U, please follow the steps below Check the package to make sure the contents is complete. Prepare one Ethernet HUB or Router Check the voltage of the power supply to make sure it is AC 110-240 volt Please confirm the specification of your power cable.

  • Page 10: Initial Setting

    IP POWER 9258-1U USER MANUAL 5. Initial Settings Initial setting through the Ethernet Open “IPEdit.exe”. Make sure that the IP Power 9258-U is properly turned on and there is a Ethernet connection from the RJ45 cable. In the local devices section of IPEdit all products under the same subnet network will appear. Please refer to (Figure 1.1) below:...
  • Page 11 IP Power 9258-1U is “IP9258” Please refer to (Fig. 1.2 above). 1. Double click and highlight your IP Power 9258-1U device. The default device name and IP/Network settings will all be displayed on the right hand side of IPEdit.
  • Page 12 2.) * The default IP address of the 9258-1U is 192.168.10.100. If you cannot get into the webpage of the 9258-1U, please make sure to set subnet of the IP Power 9258-1U to match with your PC Subnet Mask. To obtain the IP information manually: In Windows Go to: a.) Start...

  • Page 13: Setting Of Software Shut Down Controlled Pc/ Server

    IP POWER 1U USER MANUAL Setting of software shut down controlled PC/ Server 9258 can be used to safely turn off the PC/Server through Network. With this feature you can remotely shutdown any PC/ Server which that is connected to the IP Power 9258 through normal Windows shut down procedure.

  • Page 14: Hardware Control And Setting

    IP POWER 9258-1U USER MANUAL 6. Please fill correct information in each section : * IP9258 Address: Please type in the IP address of the 9258. * HttpPort: Fill the port of 9258, default value is 80, if amend the port in 9258 please correct.

  • Page 15: Control And Setting Throuth The Internet Explore

    Once you have typed in the correct login information click okay and you can start making changes to the web server. Control the power supply of outlets Having entered the Web Control page of IP Power 9258-1U, click the SET POWER button on the left, you can enter the IO setting page as the following figure: - 14 -...

  • Page 16: Power Supply State Query

    IP POWER 9258-1U USER MANUAL IP Power 9258-1U can control 8 outputs individually at the same time. User can choose power on or power off with an electrical outlet . User may fill in the corresponding columns with the delay time you wish in seconds, then choose the action after delay to be on or off.

  • Page 17: System Setting

    IP POWER 1U USER MANUAL System Settings of IP Power 9258-1U 1.) Setup – System Configuration System configuration page: Click on the Setup link located on the left hand column. In this page the user will be able to manually enter the...

  • Page 18: Email Settings

    * IP Address: Please type in the IP address provided by your ISP. If IP Power 9258-1U. * Subnet Mask: please type in the Subnet Mask provided by your ISP. If IP Power 9258-1U is working with a Router, please refer to the network settings of the Router.
  • Page 19 IP POWER 1U USER MANUAL For example: * Mail Server: smtp.sample.com * Port: * Pop3Server: pop3.sample.com * Password: *********** * Sender: Sample@sample.com * Receiver 1: receiver1@sample.com * Receiver 2: receiver2@sample.com * Receiver 3: receiver3@sample.com * Subject: This is the subject line * MailBody: This is the body of the email 1.) Mail Server: Outgoing Mail Server Please make sure the server is an available mail server.
  • Page 20 IP POWER 9258-1U USER MANUAL 7) Mail Body: please type the content of the mail here, it cannot be left empty. After you have finished all of the above settings, click “SAVE“ and your settings will be saved. 4.) Setting the password for IP Power 9258: Click the “Change password “...

  • Page 21: Setup Up Own Outlet Default Status

    IP POWER 1U USER MANUAL 4-2: Click “power schedule 2” to control outlet 5-8 . Support parameter of operate schedule: Disable Just Once Every day Work Day: From Monday to Friday. Weekend: Saturdays and Sundays Setup up own outlet default status: When power, each outlet will set as appointed default status 6.) Wake on LAN (WOL): Remote Wake up PC by MAC address in Ethernet (LAN)
  • Page 22 IP POWER 9258-1U USER MANUAL (2) Your network card must also support “WOL”, remember to connect your connect cable to Main board or the network card cannot send the “power on” message to your motherboard. After both the motherboard and network card have been setup, you can use WOL function by following the steps below: Step 1: Log in 9258 web page and go to “Network Wakeup”...

  • Page 23: Internal Clock Settings & Network Time Protocol (Ntp)

    * User can enter the internal clock settings : year , month, day , hour , minutes and second. * NTP function : customer can synchronize the time of IP Power 9258-1U to the Internet web address time . Please refer following the NTP server IP address : * 131.246.9.116...

  • Page 24: Firmware Update

    IP POWER 9258-1U USER MANUAL By setting the server address in IP server of advanced setup page, the user can easily search for his/her IP Power 9258-1U on internet just by searching for the name of the device. The default IP address of IP server is 220.135.169.136.

  • Page 25: Ddns Setting

    IP POWER 1U USER MANUAL 8. DDNS SETTING When the user connects to the Internet through ADSL (PPPOE Service), the IP address that you receive from ISP is usually a dynamic IP Address. Therefore when someone wants to visit your device they are usually not able to because the IP Address is dynamic and it will keep changing.

  • Page 26: Check Status Through Snmp

    Update Now to confirm completion 9. Check status though SNMP IP Power 9258-1U support SNMP V1 and V2 , user can use snmp program to get the status of each port in IP Power 9258-1U. - 25 - VER1.50...

  • Page 27: Control And Settings Through Http Commands

    IP POWER 1U USER MANUAL 10. Control and Settings Through HTTP Commands User can control the 9258’s action directly though the HTTP orders. The format of the HTTP order is: http://username:password@XXX.XXX.XXX.XXX/Set.cmd?CMD=Commnand+para1=*+para2=*+para3= *…… Explanations for the command syntax: Username: 9258’s username, default username is admin Password: 9258’s password, default password is 12345678 XXX.XXX.XXX.XXX the IP Address of 9258 CMD=***Power : the function module of 9258...
  • Page 28 IP POWER 9258-1U USER MANUAL Password: 12345678 (Password of the device) When you use this command, 9258 you will get the following message output : <html>P60=1,P61=1,P62=1,P63=0 , P64=1,P65=1,P66=1,P67=0</html> * Schedule Control: User can use HTTP command to arrange the 9258 operation in specific time ，http command format as follow: http://username:password@XXX.XXX.XXX.XXX/Set.cmd?

  • Page 29: Faq

    A1: Use username "super user" when log in webpage and then click "OK " turn power off for few second and then turn on ON . IP Power 9258-1U will to set back to default password. ( There is space between super and user.
  • Page 30 IP POWER 9258-1U USER MANUAL Step 2 : Open amend webpage “ipcontrol “ html file : Step 3. Amend webpage by HTML langrage( get from right click as in amend webpage”): Step 4 :Save file format as “UNIX” : Like choose “DOS to UNIX - 29 - VER1.50...
  • Page 31 IP POWER 1U USER MANUAL Step 5. After amend the other 9258 webpage you plan to amend . Please open program “Make9258Html “ in 9258 web page SDK and just press” make html patch”. Step 6 . There will be a new file “ Update_2006-01-11.bin” which is the BIN file include the amend webpage. Please follow 9258 update procedure to update the firmware BIN file .
  • Page 32 IP POWER 9258-1U USER MANUAL Set the “Bits per second” as 19200 at COM1 ( Must at COM1) 4. Then power ON 9258 you will get message in Hyper Terminal . Please check the message and get your IP address.
  • Page 33 IP POWER 1U USER MANUAL 6. Use this IP address to update again. We supply original firmware V1.22 for update f 7. Log tin this address to update again. 8. If still can not finish update successful, please check if create BIN file too big . If need to ship BIN file, please use bin file V1.22.bin in SDK to update back to factory version.
