Heiman HS1DS-Z User Manual

55mm 55mm
This is a intelligent door sensor , adopts super
low power Z-Wave wireless networking technology,
Smart Door Sensor
makes a longer battery life-span, Feel open or
close state of the door or window through the near
User Manual
and separation between sensor and magnetic.
Dual sensor design, makes the installation more
M417-1Ever1.0
flexible and adaptable. Products are suitable for
home, villas, factories, shops, warehouses, office
buildings, banks, room and other places of safety
prevention.
Networking Indicator
*Please read the user manual carefully before operation.
The guide picture is for reference only, please in kind prevail.
1
Step 3 Step 4

Anti-tamper key

- - + +
- -
+ +
Connecting network: According to the APP tip, press the device
networking hole for 3 times in 1.5 seconds, then the green LED
Align the installation, the installation distance is less
flashes quickly (connecting network within 30 seconds), and
than 15mm. (The magnet part can be installed both
"networking succeed " will be displayed on app interface.
Disconnecting network: Click the "delete device" button on APP,
sides of detector part)
then quick press networking hole for 3 times in 1.5 seconds,
green LED flashes for 6 times, disconnecting network succeed.
6 7
制作要求：
1、制作尺寸：330*55mm
2、六折扇形折页折法，折叠后尺寸为55*55mm
3、120g铜版纸彩色印刷
55mm
1. Working Voltage ：DC3V (2 pcs AAA battery )
2 . Static current ：≤5uA
：≤35mA
3 . Alarm current
4 . Detecting distance ：＞20mm
5.

Networking

：Z-Wave Ad-Hoc Network
6 . Wireless networking distance ：≥70 metres in
）
the open area
7. Working environment ：-10℃ ～ +50℃；
8. Working humidity maximum 95%RH（No ：
condensation）
：
9 . Detector dimension 76 * 36.6* 16.5 mm
10. Magnet dimension ：76 * 13.9* 16.5 mm
Sensor Magnet
2
Step 5
Tear off the gummed film, stick the equipment on the required area.
Sensor should be installed in fixed area like door frame, magnet can
be installed in active area like door plank, this picture for reference only.
8
55mm 55mm
Step 1
Remove insulator make device on power.
3 4
-
- +
+
-
+
Please change the battery according to negative
and positive of the battery.
Please deal with waste batteries correctly for
Long press the networking button,then power on (put into
environmental protection.
battery),ID code is clear and recover to factory setting.
Please use the reset procedure only when the
primary controller is missing or inoperable.
9 10
名 称 ：
智能门磁探测器中性英文说明书
型 号 ：
HS1DS-Z
物料编号 ： 601010835
版 本 ： M417-1Ever1.0
材 质
：
单 位 mm 图
：
55mm
Step 2
Click the "add" button to enter the networking mode.
5

Association Group

Association Group: Lifeline association group
Group Number: 1 Maximum Nodes:5
Description: Include command classe: Battery report, Notification report, and
Device Reset Locally notification, Binary report.
Association Group: Root Device group(Binary Sensor)
Group Number: 2 Maximum Nodes:5
+
Description: Binary Sensor Command Classes:Compatible with 300 series
1-Binary Sensor reports status of open or close door via Lifeline.
2-When the sensor detects status change between close door and open door,
the device will be triggered.
Association Group: Root Device group(Binary Sensor)
Group Number: 3 Maximum Nodes:5
-
Description: Binary Sensor Command Classes:Compatible with 300 series
1-Binary Sensor reports the removed status of door sensor.
2-When the sensor detects status change of tamper, the device will be triggered.
Association Group: Root Device group(Notification)
Group Number: 4 Maximum Nodes:5
Description: 1-Notification report open door or close status via Lifeline.
2- When the sensor detects status change between close door and open door,
the device will be triggered.
Association Group: Root Device group(Notification)
Group Number: 5 Maximum Nodes:5
Description: 1-Binary Sensor reports the removed status of door sensor.
2- When the sensor detects status change of tamper, the device will be triggered.
11
：
