Hanna Instruments HI759 Instruction Manual

INSTRUCTION MANUAL
HI759
Maple Syrup Digital Grader
Thank You
Thank you for choosing a Hanna Instruments product. Please read
this instruction manual carefully before using the instrument.
For more information about Hanna and our products,
visit www.hannainst.com.
For technical support, contact your local Hanna office or email
us at tech@hannainst.com
Find your local Hanna office on www.hannainst.com

Preliminary Examination

Please examine this product carefully. Make sure that the instrument is not
damaged. If any damage occurred during shipment, please notify your Dealer.
Each HI759 meter is supplied complete with:
• (3) Sample cuvettes and caps
• Glycerol reference cuvette
• (3) 20 mL beakers
• 1.5V AAA battery
• Instruction manual and quick reference guide

Specifications

Range 0 to 100% transmittance
Resolution 1% transmittance
Accuracy ±4% transmittance
Light Source light emitting diode @ 560 nm
Light Detector silicon photocell
Environment 0 to 50°C (32 to 122°F); RH max 95% non-condensing
Battery Type (1) 1.5V AAA
Auto-off after ten minutes of non-use
Dimensions 86.0 x 61.0 x 37.5 mm (3.4 x 2.4 x 1.5")
Weight 64 g (2.3 oz)

Functional Description

Cover
Cuvette with cap
Cuvette holder
LCD Liquid Crystal Display
Operation button

Errors and Warnings

Light High: There is too much light to perform a measurement.
Please check that the cover is fully closed, and that the glycerol
reference cuvette was used properly.
Light Low: There is not enough light to perform a
measurement. Check to see if the light is blocked or dirty.
Do not use a syrup sample to calibrate the meter.
Inverted Cuvette: The glycerol reference cuvette and sample
have been inserted in the wrong order. Otherwise, check if the
cuvette has been inserted upside down.
Under Range: A blinking "0" indicates that the sample absorbs
less light than the zero reference.
Over Range: Over Range: A flashing value of the maximum
concentration indicates the reading is over range. Dilute the
sample and re-run the test.
Low Battery: The battery is low and must be replaced soon.
Normal operation of the instrument will not be interrupted.
Dead Battery: The battery is dead and must be replaced.
Once the battery display is flashing, normal operation of the
instrument will be interrupted. Change the battery and restart
the meter.
