A) Introduction

The Falcon Predator EVO4 is a unique Vehicle Security System with Remote Engine Starter
System and is designed to provide the highest level of security and convenience.
The Falcon Predator EVO4 has many programmable functions so please read this manual
carefully before installing the Falcon Predator EVO4 system.

A-1) Features

01> Code Hopping and Code Learning
Remote System
02> Up to 4 remote transmitters
Programmable
03> Remote Engine Start
04> Remote Arm/Disarm
05> Mute Arm/Disarm
06> Immobiliser
07> Remote Boot Release
08> Passive or Active Lock Programmable
09> Auto Re-arm
10> Lock/Unlock on driving
11> Silent Car Finder
12> Defective Zone Alert and By-pass
13> Keyless Entry While Ignition is on
14> Remote Panic
Button
Press Button (1) once
Press Button (1) over 2 sec.
Press Button (2) once
Press Button (2) over 2 sec.
Press Button (3) once
Press Button (3) over 3 sec.
Press Button (1)+(2) then Button (1)
Press Button (1)+(2) then Button (1) +(2)
Press Button (1)+(3)

B) Remote Transmitter Code Learning

a> Follow the below procedure to program a new remote control.
With the alarm disarmed, and the doors CLOSED, switch the ignition ON/OFF 3 times (within 1
second of each other) and then back to the ON position.
The siren will chirp 2 times to indicate the alarm is in code learning mode.
b> To program the new remote control press button (1) within 10 seconds.
The siren will chirp twice and the hazard lights flash twice to confirm that the code has
been learned. Follow the same procedure for second, third and fourth remote transmitter.
c> If the ignition is turned OFF or button (1) is not pressed within 10 seconds, the system will
quit the code-learning mode. If this happens you must start again from the first step.
d> Up to 4 remote control transmitters can be programmed to the system.
15> Remote Anti-Hijack
16> Emergency System Override
17> Remote Valet Mode
18> Last Door Arming
19> Siren Chirp programmable for 30 or 60
seconds
20> Built-In Central Locking Control
21> Central Lock Active Time selectable 0.5
or 3.5 seconds
22> Plug-In Dual Stage Shock Sensor
23> Shock Sensor By-pass
24> Intrusion Indication by chirp when
disarmed
25> Ignition Auto Lock/Unlock
26> Siren or Horn selectable
27> Interior Light Delay Time programmable
28> 24hr Engine start
Ignition Off
Arm / Disarm
Panic
Boot Release
Aux (Channel 3) Output
Car Finder
Remote Start On/Off
Mute Mode
24-Hour Engine Start Mode
Ignition On
Lock/ Unlock
Panic
Boot Release
Aux (Channel 3) Output
Anti-Hijacking
Valet Mode
24-Hour Engine Start Mode
