MCOHome MH3700-HP-US User Manual

MCOHome programmable thermostat is a Z-Wave enabled device for indoor temperature
control. It is mainly applied to heat pump system for heating/cooling, with 3 modes easily
switchable: Event, Hold and Holiday. The device is of high reliability and practicability. This
product can be included and operated in any Z-Wave network with other Z-Wave certified devices
from any other manufacturers.
Features：
Individual programming events
4.0 inches display, Blue backlit, bright and clear
PC + ABC fire-proof enclosure
NTC thermistor
Built-in Z-Wave module (US)
Power supply： AC24V, 50Hz, 2 AA batteries (only for back-up)
Power dissipation：
Dimension: 105*140*29mm
Output: 1A (resistive load)
Temperature range: 41ºF -99ºF (5ºC -37ºC)
Display accuracy: ±0.5 ºC
Wiring: Terminals
Installation dimension: 82mm (hole pitch)
To protect yourself and others from danger and to protect the device from damage, please read the
safety information before using it.
Important!
 A qualified electrician with the understanding of wiring diagrams and knowledge of electrical
safety should complete installation following the instructions.
 Before installation, please confirm the real voltage complying with the device's specification.
Cut off any power supply to secure the safety of people and device.
MCOHome Technology Co., Ltd 2014
www.mcohome.com

Programmable Thermostat

MH3700-HP-US
Introduction
Specification
50mA
Safety Information
1
User Manual
