INSTRUCTION MANUAL
DPG-010 DIGITAL PITCH GAUGE
The digital pitch gauge is designed for application in model helicopters and serves to measure
the rotor blade pitch value.
The built in digital gyroscopic sensor is capable of detecting pitch angle, with result displayed
through LCD screen, providing a simple and precise way of measuring pitch angle.

FEATURES

Large LCD for easy reading
Up to 700 mm blades (Suitable for 250 to 700 size helicopters)
Fast and accurate measurement
Zero function
Auto rotating display
Auto power-off (Power shuts down after 20 minutes without any movement)

SPECIFICATIONS

Body Dimension
Suitable blade width
Detectable pitch range
Temperature

ILLUSTRATION

Blade Clamp
113x56x14mm
20mm~75mm
±90°
0~40°C
LCD Display
Resolution
Current consumption
Battery
Weight (including battery)
PULL OFF THE INSULATION
PAPER BEFORE USE
- 1 -
0.1°
2.8mA
CR2032 Lithium X2
40g
Power and
Zero Button
