SUN STORAGE J4500 ARRAY SETUP
CONTENTS
SLIDE RAIL INSTALLATION

FRONT PANEL

System power LED
System fault LED
Locate button/LED

BACK PANEL

Locate button/LED
System fault LED
System power LED
See the X4500-J Slide Rail Installation Guide for more information
on attaching rack slide rails and installing your array in a rack.
820-7238-XX
Power/Standby button
Top fault LED
Rear fault LED
Over temperature LED
AC power (110-220 VAC)
Power LED
Fault LED Fault LED Power LED
WWN XXX ADDRESS
5080020XXXXXXXXX
SAS ID
SAS Link/Activity LEDs SAS LinkActivity LEDs
Two mini-SAS x4 ports
(Secondary)
AC Power Cords
(Shipped separately)
Mini-SAS Cables
http://docs.sun.com/app/docs/prod/j4500.array
USB ports - Not used
AC power (110-220 VAC)
Chassis ground
System Controller LEDs
Enclosure reset button
SAS Link/Activity LEDs
Two mini-SAS x4 ports
(Primary)
Inner rails shown
removed from
outer rails.
X4500-J Slide Rail Kit
Supported cabinets:
• Sun™ Rack 1000-38
• Sun Rack 1000-42
• Sun Rack II 1042/E
• Sun Rack II 1242/E
Serial number labels on ledge
