Insignia NS-CAHBTAD Quick Setup Manual

QUICK SETUP GUIDE
Bluetooth
Receiver
NS-CAHBTAD
Designed for use with Beats Studio and Solo.
Before using your new product, please read these instructions to prevent any damage.
PACKAGE CONTENTS
• Bluetooth receiver
• Micro USB cable
• Foam spacer
• Quick Setup Guide
FEATURES
Inside view Outside view
1 3.5 mm headphone plug
2 Microphone
3 Micro USB charging port
4 Volume up/Next
5 Multi-function button (MFB): Power on/off,
play, pause, call
6 Volume down/Previous
7 LED indicator
CHARGING YOUR RECEIVER
Fully charge your receiver before you use it for
the first time. When the red LED starts to blink
during use, the battery is low and needs
charging.
1 Plug the micro USB end (small plug) on the
USB cable into the micro USB port on your
receiver.
2 Plug the USB end (large plug) on the cable
into an active USB port or any USB charger.
The LED lights red while charging. When fully
charged, the LED turns off. Charging may take
up to three hours.
3 When charging is complete, unplug the USB
cable from your receiver. Your receiver is
ready to use.
PAIRING YOUR RECEIVER
To get started, you need to pair your receiver
with your phone or device.
1 With your receiver turned off, press and hold
the MFB until the LED starts flashing blue
(about three to five seconds). Your receiver
turns on and enters pairing mode.
2 Turn on the Bluetooth feature on your phone
or device, then search for and click your
receiver (NS-CAHBTAD). See the instructions
that came with your Bluetooth device for
information about pairing.
3 If you are asked for a password, enter 0000.
When pairing is complete, the LED lights solid
blue.
RECONNECTING TO A PAIRED DEVICE
1 Turn on your receiver. It automatically
connects to the last connected device.
2 If your receiver does not automatically
reconnect, reselect NS-CAHBTAD on your
Bluetooth device.
If you want to pair with another device, turn off
the Bluetooth feature on the connected device,
then repeat the pairing procedure to connect to
a new device.
Note: If your receiver is not paired to a Bluetooth
device for three minutes, it automatically turns off.
USING YOUR RECEIVER
1 Press and hold the MFB for three to five
seconds to turn on your receiver. The LED
lights solid blue when your receiver is
connected to a Bluetooth device (for
example, your phone).
2 Insert the 3.5 mm headphone plug into the
3.5 mm audio jack on your headphones.
Make sure that the plug is fully inserted.
Headphones not included
3 To turn off your receiver, press and hold the
MFB for two seconds.
