Shark Navigator Lift-Away PRO Quick Start Manual

Shark Navigator Lift-Away PRO Quick Start Manual

Assembly; simple steps to get you cleaning with your new shark navigator lift-away pro vacuum.

Advertisement

Quick Links

Please be sure to read the enclosed Shark
f
e
d
g
c
b
a
TOLL FREE: 1-800-798-7398
CARPET AND BARE FLOOR CLEANING:
1 Attach floor nozzle (a) into the bottom of
the canister (b).
2 Insert extension wand (c) into the back of
the canister, slide on the accessory holder
(d) and place the onboard tools on the
holder (e).
3 Insert handle (f) into the top of the
extension wand and connect the hose (g)
to the back of the canister.
Owner's Guide prior to using your unit.
®
QUICK START GUIDE: ASSEMBLY
Simple steps to get you cleaning with your new
Shark Navigator® Lift-Away® Pro vacuum.
PORTABLE LIFT-AWAY
1 Detach handle (or handle with extension
wand) by pressing the handle release
button.
2 To detach the canister, place foot on floor
nozzle, press red nozzle release button
(h),then lift the canister off the nozzle .
3 Attach desired tools to handle to clean.
h
®
:
sharkclean.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Navigator Lift-Away PRO and is the answer not in the manual?

Questions and answers

Summary of Contents for Shark Navigator Lift-Away PRO

  • Page 1 Please be sure to read the enclosed Shark Owner's Guide prior to using your unit. ® QUICK START GUIDE: ASSEMBLY Simple steps to get you cleaning with your new Shark Navigator® Lift-Away® Pro vacuum. CARPET AND BARE FLOOR CLEANING: PORTABLE LIFT-AWAY ® 1 Attach floor nozzle (a) into the bottom of 1 Detach handle (or handle with extension the canister (b). wand) by pressing the handle release button. 2 Insert extension wand (c) into the back of the canister, slide on the accessory holder 2 To detach the canister, place foot on floor (d) and place the onboard tools on the nozzle, press red nozzle release button holder (e). (h),then lift the canister off the nozzle . 3 Insert handle (f) into the top of the 3 Attach desired tools to handle to clean. extension wand and connect the hose (g) to the back of the canister. TOLL FREE: 1-800-798-7398 sharkclean.com...
  • Page 2 QUICK START GUIDE: USE AND CARE I MPORTANT: Loss of Suction may occur if foam filters are not cleaned every 3 months. Rinse and allow to air-dry completely. Also, tap loose dirt off filter between washes as needed. Foam filters may appear dirty after use - this is normal. Please refer to the maintenance section of the Owner's Guide for instructions on cleaning the filters. = Carpet Cleaning = Bare /Above Floor = OFF BRUSHROLL ON/OFF: SUCTION CONTROL INDICATOR LIGHT EMPTYING THE DUST CUP 1 Press the ON/OFF switch at This vacuum has huge suction The motorized brush indicator 1 Pull up the latches on the sides the top of the canister to the I power. The suction can be light will illuminate Green when of the dust cup to release. position to vacuum bare floors adjusted to make the vacuum motorized floor brush is on. If 2 Hold the dust cup over a trash (straight suction only) or use easier to push and pull on certain there is a blockage or jam, the receptacle and press the bottom Lift-Away ® mode. To vacuum types of carpets as needed. light will turn Red (see page 9 of door release button.
