testo 545
Luminous intensity measuring instrument
Instruction manual
en
DataLoggerStore
1.877.766.5412
www.
.ca
Shop for Data Logging products online at:

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 545 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for TESTO 545

Summary of Contents for TESTO 545

  • Page 1 545 Luminous intensity measuring instrument Instruction manual DataLoggerStore 1.877.766.5412 www. Shop for Data Logging products online at:...

  • Page 2: Table Of Contents

    Clearing memory contents / Sample printouts ........18 According to the conformity certificate, the instruments fulfill 2004/08/EEC guidelines. © 1999 Copyright Testo GmbH & Co. The software and software structure included in the product testo 545 are protected by copyright laws worldwide. DataLoggerStore 1.877.766.5412 www.
  • Page 3 Contents Instrument configuration ............19 Power save function .

  • Page 4: Initial Operation

    Initial operation Please read prior to measurement Do not measure on live parts. Observe storage and transport temperature and max. operating temperature (e.g. protect measuring instrument from direct sunlight) The V24 cable (PC connection) can be inserted anytime. A simultaneous print command is not possible if the PC cable is connected. Opening the instrument, inexpert handling and use of force cancels your warranty.

  • Page 5: First Measurement

    First measurement The description of the instrument and an overview of the controls provide a quick introduction. You will receive up to date readings once the instrument is switched on. However, you will still need to update or define the data in the instrument: Date/Time: Instrument configuration...

  • Page 6: Instrument Description

    Instrument description Keyboard/Connection assignment Keypad: On/Off Prints Confirms menu setting/ executes function Saves Return to current measurement/ location selection Arrow buttons move the cursor Hold Max Min Mean DataLoggerStore 1.877.766.5412 www. Shop for Data Logging products online at:...

  • Page 7: Display

    Instrument description Display → The symbols on the top line are explained below → Name of input socket and parameter → Displays reading in line 1 → Name of location → Time/number of points in mean calculation → Displays measurement functions Explanation of symbols: Counter for the log number in the memory.

  • Page 8: Overview Of Controls

    Overview of controls Current measurement Measurement functions Manual or automatic saving, depending on setting (5.) E E S S C C L L o o c c a a t t i i o o n n Freeze values Print readings Display maximum values Display minimum values •...
  • Page 9 Overview of controls Simultaneously Current measurement Instrument configuration Activate - deactivate automatic switch-off function Selection: Power supply Memory Battery - Rechargeable settings Setting: Date Setting: Time Activate manual Unit selection saving AUTO Program Factory reset automatic saving • Select no. of meas.

  • Page 10: Current Measurement

    Current measurement Switching on / Saving / Printing It is possible to activate the following functions during mea- suring at the touch of a button: Save readings. Manual or automatic saving is determined by the Battery / rech. save setting (Chapter 5). battery power 7.

  • Page 11: Measurement Functions

    Measurement functions Freezing values, maximum readings, minimum readings Current measurement M.05 N.0017 Location Museum Hold Max/Min Mean Freezing values M.05 N.0017 Save reading Print reading Museum Hold Max/Min Mean Maximum readings since M.05 N.0017 the measurement began Save maximum reading Print maximum Museum reading...

  • Page 12: Multi-Point Mean Calculation

    Measurement functions • Multi-point mean calculation Mean Current measurement M.05 N.0017 Location Museum Hold Hold Max/Min Hold Max/Min Mean Hold Max/Min Mean Mean Max/Min Mean Multi-point mean calculation M.05 N.0017 Applies only to parameter on first line Note on saved or printed logs: 1.
  • Page 13 Measurement functions Timed mean calculation Mean Current measurement M.05 N.0017 M.05 N.0017 Hold Max/Min Hold Mean Max/Min Hold Mean Max/Min Hold Mean Max/Min Museum Hold S S T T A A R R T T Mean Start timed mean calculation. Max/Min 00: 0 0 Mean...

  • Page 14: Location Selection

    Location selection The location names Location 1 to 99 are specified by the factory. M.05 N.0017 You can load your own location names (8 characters) onto your instrument using PC software. 1. Current measurement Museum E E S S C C L L o o c c a a t t i i o o n n Selection of location.

  • Page 15: Memory Settings

    Memory settings OVERVIEW Press the 1. Current measurement button to get to the memory settings mode. Confirm flashing save symbol button. M.05 N.0017 4 memory settings are possible. Select the required saving option by pressing AUTO CLEAR Museum The symbol corresponding to the selection appears in the top line. The function is activated with Location Parameter settings...

  • Page 16: Manual / Automatic Saving

    Memory settings Manual / Automatic saving Press the button to get to the memory settings mode. Confirm flashing save symbol button. M M A A N N AUTO Manual saving: M.05 N.0017 Each time is pressed a log of the measurement is saved in MEMORY the instrument and includes measured values, location, date and time.

  • Page 17: Reading Out Or Printing Memory

    Memory settings Reading or printing memory Press the button to access the memory settings mode. Confirm flashing save symbol via the button. Cancel printout by pressing the button. O O U U T T CLEAR Location 1. Reading out or printing memory contents: MEMORY If the “OUT”...

  • Page 18: Clearing Memory Contents/Sample Printouts

    Memory settings Clearing memory contents/Sample printouts Press the button to access the memory settings mode. Confirm flashing save symbol via the button. Clearing memory: CLEAR N N O O Y Y E E S S C C L L E E A A R R CLEAR CLEAR MEMORY...

  • Page 19: Instrument Configuration

    BAT: Battery operation with 9 V block battery, Alkali manganese IEC 6LR61. AKKU: Rechargeable battery operation with Testo B B A A T T AKKU rechargeable battery (Part no. 0515.0025), Type: Ni-MH IEC 6F22.

  • Page 20: Setting Date/Time

    Instrument configuration Unit selection / Factory reset / Power supply DATE 01. 0 1 9 9 8 8 Setting date The flashing position in the display can be set = scroll/ = next position - Setting the time TIME 11: 2 5 The blinking position in the display can be set = scroll/ = next position -...

  • Page 21: Error Messages

    Measuring range has not The measured values are been reached outside the allowed measuring range. Switch resolution. Connection to the probe Please contact a Testo has been interrupted. service point. DataLoggerStore 1.877.766.5412 www. Shop for Data Logging products online at:...

  • Page 22: Technical Data

    Technical data Sensor: Silicon photodiode Meas. range: 0 to 100,000 Lux To DIN EN 13032-1 Accuracy: f1 = 6 % f1 = V (l) adaptation f2 = 5 % f2 = cos like rating Resolution can 0 to 32,000 Lux 1 Lux be switched: 0 to 100,000 Lux 10 Lux 0 to 3.200 fc...

  • Page 23: Ordering Data

    0554.0830 incl. data base, analysis and graphics function, data analysis, trend curve Transport case 0516.0445 For safe storage of measuring instrument, TopSafe, probe and Testo log printer RS232 cable 0409.0178 Connects measuring instrument PC for data transmission ISO calibration certificate 0520.0010...
  • Page 24 0973 5450 en 03 V01.70 DataLoggerStore 1.877.766.5412 www. Shop for Data Logging products online at:...
