Swift1915Z Aura LED Moving Head Beam Wash Light User Manual
Tilt Inverse
Select Tilt Inverse, press ENTER button to confirm, present mode will blink on the
display, use UP and DOWN button to select No (normal) or Yes (tilt inverse), press
ENTER button to store. Press MENU button back to the last menu or let the unit idle
one minute to exit menu mode.
P/T Feedback — Pan/Tilt Feedback
Select P/T Feedback, press ENTER button to confirm, present mode will blink on the
display, press UP/DOWN button to select No (Pan or tilt's position will not feedback
while out of step) or Yes (Feedback while pan/tilt out of step), press ENTER button to
store. Press MENU button back to the last menu or let the unit idle one minute to exit
menu mode.
BL.O. P/T Moving
— Blackout while pan/tilt moving
Select BL.O. P/T Moving, Press ENTER button to confirm, present mode will blink on
the display, use UP and DOWN button to select No (normal while pan/tilt moving) or
Yes (blackout while pan/tilt moving), press ENTER button to store. Press MENU button
back to the last menu or let the unit idle one minute to exit menu mode.
White Balance
Select White Balance, press ENTER button to confirm, present mode will blink on the
display, use UP and DOWN button to select Red, Green or Blue, Once selected, press
ENTER button, then use UP and DOWN button to adjust the value from 125 to 255,
press ENTER button to store. Press MENU button back to the last menu or let the unit
idle one minute to exit menu mode.
Cooling Mode
12
Swift1915Z Aura LED Moving Head Beam Wash Light User Manual
Select Cooling Mode, press ENTER button to confirm, present mode will blink on the
display, use UP and DOWN button to select Auto (Normal) or Low (Low speed), Once
selected, press ENTER button to store. Press MENU button back to the last menu or
let the unit idle one minute to exit menu mode.
Dimmer Curve
Select Dimmer Curve, press ENTER button to confirm, present mode will blink on the
display, use UP and DOWN button to select Linear , Square Law, Inverse Squ. or
S-curve, Once selected, press ENTER button to store. Press MENU button back to the
last menu or let the unit idle one minute to exit menu mode.
Linear: The increase in light intensity appears to be linear as DMX value is increased.
Square Law: Light intensity control is finer at low levels and coarser at high levels.
Inverse Square Law: Light intensity control is coarser at low levels and finger at high
levels.
S-cure: Light intensity control is finger at low levels and high levels and coarser at medium
levels.
Display Setting
Enter MENU mode, select Display Setting, press ENTER button to confirm, use UP
and DOWN button to select Display Inverse, Backlight Auto Off,
