EDISecure DCP 350 Quick Start Manual

DCP 350 Direct Card Printer
Quick Start Guide
This printer package contains,
EDIsecure® DCP 350 Direct Card Printer / Power Adaptor / Power Cord / USB Cable /
Ribbon Cartridge (included in Printer) / Qucik Start Guide (this document) / Software Installation CD
01
Open the top cover and
take out the empty ribbon
cartridge.
06
Install the ribbon cartridge
to the printer and close the
top cover.
11
Select "English" and Click
"Next" in STEP 1.
This step may take a few mo-
ments.
16
Select "Yes, this time only" and click
"Next". Select "Install the software auto-
matically" and click "Next" in 'Found New
Hardware Wizard' window.
11
When "User Account Control"
window is opened, click "Yes".
16

Search DCP 350 connected in the network.

Click "OK" after selecting and click "Next". If
the printer is not found, please do network
setting by referring to "DCP 350 user manual".
Quick_Start_guide_DCP350_A2_V1-1.indd 1
02 03
Prepare the ribbon and rib-
bon cartridge.
07 08
Open the hopper cover and
place the card.
12 13
Click "Next"in STEP2.
17 18
When Hardware Installation window
appears click "Continue Anyway". When
installation is completed click "Finish".
This step may take a few moments.
12 13
Select "English" and Click
"Next" in STEP 1. This step may
take a few moments.
17 18
Click "Close" after installation is
completed.
04
Install supply core and Install a disposable clean-
take-up core to the halls ing roller in the ribbon
and press the opposite sides cartridge.
until they click.
09
Connect the power cord and

Insert Installation CD.

USB.
14
When the software installation Plug in your card printer, check the printer is con-
window appears click "Con- nected and turned on. This step may take a few mo-
tinue Anyway". ments. In case of USB connection, click "Next" and
move to No.16. In case of Network, move to No.15.
19
Right click on "DCP 350" Card Select the "General" tab and
Printer and select "Properties". click " Print test page".
14
Click "Next" in STEP 2. If the Windows security warn-
ing appears click "Install this
driver software anyway".
19
Open "Drivers and Printers" Select the "General" tab.
and right click on "DCP 350
Direct Card Printer". Select
"Printer Properties".
theRe IS one foR eveRyBoDy
05
Peel the protective paper off
on the disposable cleaing
roller.
10
Click "Driver Install".
15
Search DCP 350 connected in the network.
Click "OK" after selecting and click "Next". If
the printer is not found, please do network
setting by referring to "DCP 350 user manual".
20
Check if card is printed
properly.
15
Plug in your card printer, Check the printer is con-
nected and turned on. This step may take a few
moments. In case of USB connection, click "Next" and
move to No.17. In case of Network, move to No.16.
20
Check if card is printed
properly.
