- Page 1 WMA-5 Gas Analyzer Operation Manual Version 1.01 2015 PP Systems. All Rights Reserved November 2016 PP Systems 110 Haverhill Road, Suite 301 Amesbury, MA 01913 U.S.A. Tel: +1 978-834-0505 Fax: +1 978-834-0545 Email: support@ppsystems.com URL: www.ppsystems.com...
-
Page 2: Table Of Contents
Unpacking .............................. 7 Technical Specification ..........................8 Summary of System Design .......................... 9 Overview and Theory ..........................9 Optional Sensors for use with WMA-5 ......................11 Sensor ..............................11 O Sensor .............................. 11 Mechanical Specifications & Mounting Instructions ..................11 System Power ............................. - Page 3 Set Clock Settings ..........................35 Default Settings ............................ 36 Calibration ..............................36 Calibration ............................37 Calibration ............................39 Connecting Reference Gas the WMA-5 ....................40 Touch Calibration ............................ 41 Diagnostics ..............................42 ADC Diagnostics ............................. 42 Zeros Diagnostics ............................ 43 Hours Diagnostics ...........................
- Page 4 Communication Summary ........................58 Wireless Network Settings........................58 Connecting To WMA-5 Via Direct Wireless Connection ..............59 Connecting to WMA-5 via a Local Area Network ................60 Measure Format Settings Table ........................63 Error Messages for the WMA-5 Table ......................66 Maintenance ..............................
- Page 5 Federal Communication Commission Interference Statement ............73 Radiation Exposure Statement ......................74 WMA-5 Operation Manual V. 1.01 support@ppsystems.com...
-
Page 6: Welcome
This manual and the information contained within are copyrighted to PP Systems. No part of the manual may be copied, stored, transmitted or reproduced in any way or by any means including, but not limited to, photocopying, photography, magnetic or other mechanical or electronic means, without the prior written consent of PP Systems, Inc. -
Page 7: Service & Warranty
PP Systems or an authorized agent for repair or replacement of the defective part(s). Prior to returning equipment to PP Systems for service, you must first get in contact with our Service Manager (service@ppsystems.com) to request a case number for reference and tracking purposes. -
Page 8: Technical Specification
WIFi PP Systems is a registered trademark of PP Systems, Inc. PP Systems is continuously updating its products and reserves the right to amend product specifications without notice. All brand names are trademarks or registered trademarks of their respective owners. -
Page 9: Summary Of System Design
Summary of System Design Overview and Theory The WMA-5 is designed to function as a self-contained instrument for continuous measurement of CO air. Its open-path design allows for continuous, unattended air sampling, as the pump introduces fresh sample gas to the essential component, the IRGA (infrared gas analyzer). - Page 10 Some changes may require recalibration, although one of the strengths of the WMA-5 is that recalibration is not a routine (annual) maintenance task as a result of our innovative “Auto-Zero” function. Our Auto-Zero function corrects for nearly all changes that result in calibration drifts.
-
Page 11: Optional Sensors For Use With Wma-5
Input: 12 VDC, 1.5A or 100-240 VAC, 50-60 Hz, 0.6A (AC adapter included) The WMA-5 can be powered by 12V if required via direct connection to the terminal block. It requires a 12V DC input at 1.5A. Connect the positive to +12V and the negative to GND. The terminal block is clearly marked for ease of connection. -
Page 12: Getting Familiar With The Wma-5
Data Port Touch Display The WMA-5 features a 2.7” a-Si, active matrix TFT, Electronic Paper Display (EPD) touch panel. The panel has such high resolution (117 dpi) that it is able to easily display fine patterns. Due to its bi-stable nature, the EPD panel requires very little power to update and needs no power to maintain an image. -
Page 13: Gas Ports
Gas Ports There are two gas ports (barb fittings) on the WMA-5. The gas inlet is located on the water trap and the gas outlet is located on the bottom of the WMA-5 enclosure. Each port is designed for use with 1/8”... -
Page 14: Recommended Cable Interface
Recommended Cable Interface When connecting up to external devices via the WMA-5 terminal block we recommend the following cable type and lengths. WMA-5 Terminal Block TX RS232 RX RS232 Shielded cable to PC or Data Logger Typical cable Belden 9609 4C 24 Shielded. Length 10 Ft Maximum... -
Page 15: Usb Memory Stick Port
Soda lime (Sodium Hydroxide) is used to remove CO from air entering the WMA-5. Both self-indicting (white to violet) and non-indicating Soda Lime can be can be used with the WMA-5. Refer to Soda Lime on page 68 for maintenance and replacement information. -
Page 16: Routine System Checks
Inspect gray foam filters and replace if worn or reduced in size. Touch Display Overview The flowchart below describes an overview of the touch display for the WMA-5. When the instrument is first powered up, there is a brief period where the Splash screen is shown. After this time, the instrument goes into the warm-up period which is approximately 10-15 minutes and the Measure screen is displayed. - Page 17 Analog Host Alarms Defaults Averaging WiFi Reset Abs WMA ID Memory Flow Graph Host Port Alarm Sound Reset WiFi CO2 Unit Diagnostics Calibration Info Menu Menu Menu About Zeros Contact Hours Touch Cal Voltages WMA-5 Operation Manual V. 1.01 support@ppsystems.com...
-
Page 18: Splash Screen
Data Entry Screen The Data Entry Screen is used to enter new numerical values. The screen is displayed whenever a new value is required. 1. The name of the parameter. WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 19: Measurement Mode
The Measurement Mode is comprised of four screens; Measure screen, Variables 1 screen, Variables 2 screen, and the Graphic Display screen. Each screen allows the user to view the WMA-5 data in various ways. The screens can be rotated through by the user using the left and right arrow buttons. The initial screen is the Measure screen which displays the value of CO concentration in a large bold font. -
Page 20: Measure Screen
Performing a Zero The status of ‘Z 23’ means the WMA-5 is performing a zero. The number is how many seconds it will take to complete the sequence. A normal zero starts at 25 seconds. During a Zero, the CO value is displayed as 0 as the readings are not valid during the Zero sequence. -
Page 21: Variables 1 Screen
Flow rate reading (cc/min). Press Absolute pressure in sample cell (mb). Left Arrow Button Displays the previous measurement screen, the Measure Screen. Right Arrow Button Displays the next measurement screen, the Variables 2 Screen. WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 22: Variables 2 Screen
Selectable parameter to graph (0 - 30 mb) Button Selectable parameter to graph (0 – 100 %) Y-axis Range and units are located under the graph on left side X-axis X-axis time; fixed value of 3 minutes. WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 23: Main Menu
The Main Menu screen is displayed when the Main button is selected in the Measure screen. This menu is the top level menu for all settings and user functionality of the system. Main Menu Settings Button Controls major settings of the WMA-5. There are four sub menus under Settings. Diagnostics Button Performs system diagnostics for troubleshooting purposes. -
Page 24: Settings
There are four settings menus; Settings 1-4. Generally, the settings have been grouped related to their frequency of change and common functionality. Settings 1 Menu This menu contains the first tier and most common settings for the WMA-5 including the Zero, Alarms, Reset Abs (Reset Absorber Column), Flow, Alarm Sound, and CO Units. - Page 25 Z button in the upper right hand corner of the display. User Set Button When selected, the WMA-5 performs a zero on start up, then again after 3 minutes, then again after 6 more minutes, then after 12 minutes, then finally after 20 minutes.
-
Page 26: Alarm Settings
See numerical keypad description under Zero Time section for details. The WMA-5 is supplied with a factory default low alarm setting of 250 ppm. The reason for this is that a typical low CO value is the result of one of the following scenarios: ·... -
Page 27: Reset Zero Absorber
No Button Returns to the Settings 1 Menu without resetting the Zero Absorber capacity gauge. Flow Settings This function allows the user to change/view the Flow rate of the WMA-5. Flow Settings Flow (cc/min) The measured flow rate Pump Power (%) Button... -
Page 28: Alarm Sound Settings
Sets the units for CO in the Measure Screen Display to ppm. % Button Sets the units for CO2 in the Measure Screen Display to %. Back Button Returns to the Settings 1 Menu. WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 29: Settings 2 Menu
Averaging Button Sets the CO averaging value range WMA ID Button To select an ID number of the WMA-5 Graph Button To set the CO2 Y-axis range for the graph. Back Button Returns to the Settings 1 Menu screen. -
Page 30: Averaging Settings
66 ppm; then after 16 seconds, the measured value would change by 99 ppm. WMA ID Settings WMA ID Settings WMA ID Button To Select device ID Range 0-9 (the Default is 1) Back Button Returns to the Settings 2 Menu. WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 31: Graph Setting
To select the CO2 Y-axis range for the Graph Screen Back Button Returns to the Settings 2 Menu. Max CO2 Settings Radio Buttons Selects the CO2 Y-axis range for the Graph Screen Back Button Returns to the Graph Settings screen. Settings 3 Menu WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 32: Host Settings
Determines the time interval in seconds in which the measure data will be sent. A value of 0 stops sending data. The maximum value is 3600 seconds (1 hour). Default is 0. Back Button Returns to the Settings3 Menu. WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 33: Wifi Settings
Determines the time interval in seconds in which the measure data will be sent. A value of 0 means no data sent. The maximum value is 3600 seconds (1 hour). Default is 0. Back Button Returns to the Settings3 Menu. WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 34: Host Port Settings
Returns to the Settings 3 Menu. Reset WiFi Settings Reset WiFi Settings Yes Button Reset Wi-Fi to original Factory Settings then returns to Settings 3 Menu No Button Returns to the Settings 3 Menu without resetting Wi-Fi WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 35: Settings 4 Menu
Defaults Button To reset all parameters to factory defaults This function allows the user to initialize the WMA-5 to its factory default values. This feature may be needed to correct an erroneous calibration, or to simply undo undesirable configuration changes. -
Page 36: Default Settings
Yes Button Resets WMA-5 to original factory settings then returns to Settings 4 Menu. This function allows the user to initialize the WMA-5 to its factory default values. This feature may be needed to correct an erroneous calibration, or to simply undo undesirable configuration changes. -
Page 37: Co 2 Calibration
Assuming that a calibration gas mixture is used to calibrate the WMA-5, follow these instructions: 1. To avoid excess pressure in the sample cell and possible damage to the analyzer, you must connect the sample line with a “T”... - Page 38 (i.e. it is best to calibrate the instrument with a reference gas containing 350 - 450 ppm CO when measuring around 350 ppm CO 5. The WMA-5 will then perform a zero. At completion of successful zero, a similar message to the following will be displayed. WMA-5 Operation Manual V. 1.01...
-
Page 39: O 2 Calibration
This function allows the user to recalibrate the internal O Sensor used with the WMA-5. Before calibrating, confirm that: · The WMA-5 has been on for at least 30 minutes. · The Gas Out port is unobstructed. WMA-5 Operation Manual V. 1.01... -
Page 40: Connecting Reference Gas The Wma-5
Follow these instructions to calibrate the WMA-5 O Sensor: 1. Connect the reference (sample) gas to the GAS IN port on the WMA-5 2. Select the button to the right of the “O Conc (%):” text. 3. Enter the O concentration of the reference gas. -
Page 41: Touch Calibration
1. Turn the instrument off. 2. Place your finger anywhere on the touch display and turn system power on and wait for the next screen to appear. 3. Proceed as directed with the touch screen calibration. WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 42: Diagnostics
Diagnostics This menu monitors and reports key system diagnostics associated with WMA-5 hardware. It is generally used for troubleshooting and diagnosing potential problems associated with the instrument. Diagnostic Menu ADC Button To read the CO IRGA ADC values Zero Button... -
Page 43: Zeros Diagnostics
400 ppm. Zero Button Puts the WMA-5 into “Zero” mode. In “Zero” mode, the A/D value for CR should read approximately 40000-50000 if fresh soda lime is present in the absorber column. The CR value in “Zero” mode should always be greater than the CR value in “Measure”... -
Page 44: Hours Diagnostics
Hours Diagnostics Hours Diagnostics Controller (hr) The number of Hours the WMA-5 has been Powered IRGA (hr) The number of Hours the CO2 IRGA has been Powered Back Button Returns the display back to the Diagnostic Menu. Voltage Diagnostics Voltage Diagnostics... -
Page 45: Information Menu
Information to contact PP Systems Back Button Returns to the Main Menu. About About About Provides important information related to the instrument hardware including serial number of the WMA-5 console. Back Button Returns to the Information Menu. WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 46: Contact
Contact Contact Contact Contact information for PP Systems. Back Button Returns to the Information Menu. WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 47: Connecting Wma-5 To External Devices
The USB Type A jack on the front panel is designed specifically for a USB Flash Memory Stick. Any memory stick can be used, however the low profile memory stick provided with the WMA-5 will also allow the enclosure cover to be closed with the memory stick installed. -
Page 48: Digital Connection Methods
Refer to the Error Messages for the WMA-5 table below for disk errors. Digital Connection Methods There are three ways to connect to the WMA-5 for viewing digital data: the USB port, the RS232 port and the WiFi Option (if installed). -
Page 49: Digital Communication Protocols And Software
WMA-5. If the CRC parameter value is ‘0’ (CRC Off), no CRCs will be appended to any of the commands received from the WMA-5. If the CRC parameter value is ‘1’ (CRC On), CRCs will be appended (including the ‘C’) to all commands received from the WMA-5. - Page 50 WMA-5 will send out without being prompted by the user. For example, the ‘W’ (Warm Up) command is only sent by the WMA-5 when it is warming up. Standard commands are commands that are sent by the user. <CR> represents a carriage return (ASCII 13).
- Page 51 +<CR> C,1,0,2000,1.091,0<CR> reading is 2000 and the calibration factor is 1.091. In the example, the CO E,xxx Auto This command transmits any errors. See Error Messages for the WMA-5 Table below for more details. Example, Received from WMA-5: +<CR> E,11<CR>...
- Page 52 Received from WMA-5: +<CR> T,04,42,15,05,01,15<CR> In this example, seconds=04, minutes=42, hour=15, day=05, month=01 and year=(20)15. 2. A Full Set: The ‘T’ command can also be used to set the complete set of day/time values. WMA-5 Operation Manual V. 1.01 support@ppsystems.com...
- Page 53 WMA-5 version number=01.02 IRGA serial number=IRGA00001 IRGA version number=01.02 Auto During warm up of the WMA-5, the W command is transmitted every second until the operating temperature is reached. (No “M” strings are sent during this time) Example: Received from WMA-5: W,55.0<CR>...
- Page 54 This command can be initiated by the user or by the WMA-5 itself. Example: Sent from Host: Z<CR> Received from WMA-5: +<CR> Z, 025<CR> Z, 024<CR> … A zero has been initiated by the user. In this example, xxx is 025 then 024 which counts down of the number of cycles remaining.
-
Page 55: Gas (Gas Analysis Software)
GAS (Gas Analysis Software) software is available for displaying and logging data from the WMA-5. No programming or command-line knowledge is required to utilize the GAS software. Connection between the WMA-5 and computer is via the USB interface. GAS will run on Windows XP and above. - Page 56 In the top left corner, a box will appear listing all available WMA-5 devices. Select one and click OK. After clicking OK, the main measurement screen will be displayed. WMA-5 Operation Manual V. 1.01 support@ppsystems.com...
- Page 57 Note: In the top left area, the device name (e.g., TARGAS-1, EGM-5, SBA-5 or WMA-5), serial number, and COM port are all displayed. Data is displayed both graphically and numerically. GAS gives the ability to log past data activity in a current session (Save Log) or record data (Start Record) for a time segment.
-
Page 58: Communication Summary
The following table summarizes the communication methods and protocols described in the preceding sections. In addition, other capabilities exist within the WiFi option that may be useful to some users attempting to write custom code on a wireless connection – please contact PP Systems for more information. -
Page 59: Connecting To Wma-5 Via Direct Wireless Connection
SSID of ‘WMA5’, it will be difficult to determine which WMA-5 is connected to the wireless device. When more than one WMA-5 is to be used, it is recommended to power on only one WMA-5 at a time at first, then change the SSID as described in step 8 below to a unique name that eliminates the duplicate SSIDs.) -
Page 60: Connecting To Wma-5 Via A Local Area Network
Connecting to WMA-5 via a Local Area Network Here are the steps to make a wireless connection to the WMA-5 using the Client Mode method in which the WMA-5 is connected to a user’s existing Local Area Network via a user’s existing wireless access point or wireless router. - Page 61 6. Then, once the WMA-5 is successfully connected a LAN, view the Status page under the Interface wlan0 section to see the particular IP address that was assigned to the WMA-5. In the example below, the LAN IP address 10.0.0.150 was assigned to the WMA-5 (and the softAP Interface ap0 address is still available for direct connection at 192.168.0.1).
- Page 62 Chrome™, Safari® etc.) and in the address field of the browser enter IP address assigned to the WMA-5, such as ‘10.0.0.150’ for the example shown. Some browsers interpret that address as a search term rather than a LAN IP address, so enter ‘http://10.0.0.150’ in the address bar, if necessary.
-
Page 63: Measure Format Settings Table
CRCs concatenated to the end of a message. <CR> represents a carriage return (ASCII 13). Measure Format Setting Setting Description M1 is the legacy data format used in the WMA-4 (previous model to the WMA-5). Note: this format is NOT comma delimited. An example is: M1100012801131900968115025000000000000000000000099700<CR> The format is as follows: M1: Determines what data format is being displayed. - Page 64 M3,1,0003,17,12,15,27,1095,0.0,20.41,327,0.0000,55.0, 1002.9,0x0000<CR> The format is as follows: M3: Determines what data format is being displayed. In this case M3 is Full format. WMA-id: 0-9 (Identifier for WMA-5 when multiple units are used). Record #: 1-9999 Day: 1-31 Month: 1-12 (January - December).
- Page 65 Temperature Sensor1: Relates to temperature sensor 1. Temperature Sensor2: Relates to temperature sensor 2. Lamp: Relates to lamp current. Last Zero CO : Reports last zero value. Displays IRGA error code message as a hexadecimal number. WMA-5 Operation Manual V. 1.01 support@ppsystems.com...
-
Page 66: Error Messages For The Wma-5 Table
Analyzer temperature > 60 Low Flow Error The flow is less than 50. IRGA EEProm Write IRGA unable to perform a write. If error persists, call PP Systems Fail technical support. IRGA EEProm CRC IRGA read/write EEProm CRC incorrect. If error persists, call PP Fail Systems technical support. - Page 67 Disk related message. Disk detected - This message is seen each time a disk is inserted into the drive. Disk DR Disk related message. Disk removed - This message is seen each time a disk is removed from the drive. WMA-5 Operation Manual V. 1.01 support@ppsystems.com...
-
Page 68: Maintenance
Soda Lime · The soda lime should last for 2-3 months from the time it is replaced. PP Systems used to supply a “green to brown” indicating soda lime but this type is no longer available and has since been replaced by the “white to violet”... -
Page 69: Gray Foam Filters
Part Number Description 10164-1 WMA-5 Absorber Column (Complete) 20041-2 Absorber Column (clear plastic only) 41508-1 Gray Filter Foam 30013-1 O-ring 4.47 x 1.78 30013-17 O-ring 17.6 x 2.4 STD007W Sofnolime (white to violet), 1 kg WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 70: Water Trap
(once per month). To change, gently pull one end of the filter assembly from the gas tubing and then repeat on the other side. Connect new filter assembly to the tubing and reassemble. WMA-5 Operation Manual V. 1.01 support@ppsystems.com... -
Page 71: Sampling Pump
The sampling pump used in the WMA-5 is a vibrating diaphragm type pump. It operates from 12 VAC that is generated onboard from the WMA-5 12V DC power supply. It is capable of delivering flow rates up to 500 cc/min flow. History has shown that this style pump is extremely rugged and durable and should last for many years. -
Page 72: Appendix 1. Wifi Compliance
Appendix 1. WiFi Compliance The Wireless device used in the WMA-5 is a product from Lantronix and is their xPico® Wi-Fi® Embedded Device Server (According to ISO/IEC Guide and EN 45014) Manufacturer's Name & Address: Lantronix, Inc. 167 Technology Drive, Irvine, CA 92618 USA... -
Page 73: Table C-2 Country Transmitter Ids
: Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate this equipment. This transmitter must not be co-located or operating in conjunction with any other antenna or transmitter. WMA-5 Operation Manual V. 1.01 support@ppsystems.com... - Page 74 Radiation Exposure Statement This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment. This equipment should be installed and operated with minimum distance 20cm between the radiator & your body. WMA-5 Operation Manual V. 1.01 support@ppsystems.com...
