Warranty Period : 1 year
Minoura offers 1-year limited
warranty to this product
from the date of your purchase.
Any natural wear and the
problems caused by
misuse or unapproved
modification will not be
covered by this program.
For more details, read the enclosed
Minoura Limited Warranty Policy
card in the kit.
Also please regularly check our
Minoura web site for the
latest information.
Contact
MINOURA JAPAN
(for ALL customers, including Canada)
1197-1 Godo, Anpachi, Gifu 503-2305 Japan
Phone: +81-584-27-3131
Fax:
+81-584-27-7505
Email: minoura@minoura.jp
Web:
www.minoura.jp
indoor bike trainer
––– Please read this instructions carefully before use –––
If you have questions or need help, please contact the shop where you purchased this product
or the distributor in your country first. The distributor can be found on our web site.
If your shop or distributor is unable to help you, please contact us at:
MoZ-Roller
* The Foot Step and Front Guard (included) are not shown in this image.
MINOURA NORTH AMERICA
(for the customers in the U.S.A. ONLY)
Hayward, California, USA
Phone: 1-510-538-8599
Fax:
1-510-538-5899
Email: support@minourausa.com
Made in Japan
– instructions manual
(ver.1.10 2018/4)
* Bike is not included in this kit.
(9:00 – 17:00 PST)
