Indoor Bike Trainer
[Applicable Wheel Size]
650c – 700c, 26 – 29 inch
[Applicable Wheebase Size]
950 – 1,200mm
• This trainer is designed for use only on stable or indoor surfaces. The trainer is not
Caution
designed to be used in muddy or off road conditions. Getting dirt in the resistance unit
could may cause damage. Using muddy or dirty tires will cause premature wear on the
rollers.
• Using wheels smaller than 24" will put too much stress on the unit.
• When setting up the FG540 pedal slowly at first to make sure the rear wheel stays on
the roller and is positioned properly.
If you need help, please contact the shop first where you originally purchased this product or call the distributors
Contact
in your country. The distributors list can be found on our web site.
MINOURA North American Tech Center
(for U.S. residents ONLY)
Hayward, California, U.S.A.
Phone: 1-510-538-8599 (8 am - 5 pm, Mon - Fri, PST)
Fax:
1-510-538-5899
Email: support@minourausa.com
MADE IN JAPAN
(Shown with 700c road bike)
MINOURA Japan Headquraters
(for ALL customers)
1197-1 Godo, Anpachi, Gifu 503-2305 Japan
Phone: +81-584-27-3131
Fax:
+81-584-27-7505
Email: minoura@minoura.jp
Web: www.minoura.jp
(ver.1.2 2016/12)

Advertisement

loading
Need help?

Need help?

Do you have a question about the FG540 HYBRID ROLLER and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for MINOURA FG540 HYBRID ROLLER

Summary of Contents for MINOURA FG540 HYBRID ROLLER

  • Page 1 If you need help, please contact the shop first where you originally purchased this product or call the distributors Contact in your country. The distributors list can be found on our web site. MINOURA North American Tech Center MINOURA Japan Headquraters (for U.S. residents ONLY) (for ALL customers) Hayward, California, U.S.A.

  • Page 2: Important Notes

    For this reason, the bolts which hold the bushing are not fully tightened intentionally and there is some space above the bolt. • Minoura recommends the use of a completely slick (no tread) tire to reduce noise and increase the longevity of the tire and rollers.

  • Page 3: Part Names

    Part Names Front Fork Support Adapter Sleeve for 15mm Thru Axle (9mm Q/R, 15mm Thru Axle compatible) (Red, inside) Stopper Pin Knob Lever (backside) Front Frame Tripod Left Side Leg Remote Cable Guide (backside, Right side only) Remote Shifter Front Frame / Tripod Center Leg Front Roller (free spinning side)
  • Page 4 Flip out the retracted center frame, and place on the floor. Loosen the center frame locking knob to prepare for sliding. Connect the center frame to the tripod center leg. Tighten the Q/R firmly. Assembling FG540 is now finished. Firmly tighten the Q/R.
  • Page 5 How To Adjust The Front Fork Support Height Turn the knob lever counter-clockwise to loosen, Slide down the fork mount until the stopper pin and pull up the front fork support. reaches the front frame. The lever becomes free by pulling the lever. You can set the lever at your favorite angle.
  • Page 6 How To Use The 15mm Thru Axle Required Tool : 3mm Hex Wrench (not included) The front fork support is compatible with both the standard 9mm quick release (The bottom side of the fork mount) skewer and the 15mm thru type axle. To use 15mm thru axle, remove the headless bolts under the sleeve guide end in the fork mount (do not remove the normal bolts) and pull out both the red adapter sleeve and the Q/R.
  • Page 7 The rear tire sits in the center of the roller and doesn't touch any other parts. Adjust the center frame position properly that the rear tire contacts both rollers. If the tire touches the rear roller only and a clearance exists between the tire and the front roller, the center frame repeats jumping while riding.
  • Page 8 How To Operate Remote Shifter Required Tool : 4mm Hex Wrench (not included) FG540 comes with a convenient remote shifter device. By installing it on your handlebar or stem, you can adjust the resistance level in 13 levels without getting off the bike. The plastic band is soft enough to fit aero-shaped carbon handlebar or round shaped stem as well as the standard round dimension handlebars.
  • Page 9 To do so, use an M4 hex wrench to loosen the previously mentioned bolts while sliding the mag unit forward to increase the tension on the belt until the correct tension has been achieved. MINOURA JAPAN 1197-1 Godo, Anpachi, Gifu 503-2305 Japan / Web: www.minoura.jp / Mail: minoura@minoura.jp...
