review Data
select "review data" from main menu.
main menu
1. Quick test
2. Battery in Vehicle
3. out of Vehicle
4. review data
5. Print data
6. system setup
check the battery testing results.
Healthy:96%
charge:98%
internal r=6.1mΩ
rated:500A
Good BAtterY
5.6. Print Data.
Before selecting the print data function, it is necessary to connect the Battery tester to the computer via the usB cable.
insert the cd into the computer.
At prompt install usB driver
manual
Print software
usB driver
read me.txt
open the Print software.
choose the com Port no (delete any data history on the system)
on the battery tester screen select Print data from the main menu.
main menu
1. Quick test
2. Battery in Vehicle
3. out of Vehicle
4. review data
5. Print data
6. system setup
once the data is transferred to the computer, the print software will show the following.
Healthy:96%
charge:98%
internal r=6.1mΩ
rated:500A
Good BAtterY
the Battery tester will show the following menu.
Print data
oK
Press exit to return to main menu
After testing remove usB lead from computer / tester and store tester and leads in a dry, childproof location.

6. MaintenanCe

Keep Battery tester, leads, disc and instructions clean and store in a dry, childproof location.
© Jack sealey limited
490ccA
12.64V
490ccA
12.64V
Original Language Version Bt105 | issue:1 09/05/16
