input correct rating and press enter Key. it takes approx. 3 seconds to display the battery test results.
select input
500
ccA
battery test results
good battery
Healthy:96%
charge:98%
internal r=6.1mΩ
rated:500A
Good BAtterY
there is no problem with the battery and is ok to use.
good recharge
Healthy:78%
charge:30%
internal r=7.2mΩ
rated:500A
Good, recHArGe
Good battery but low current, recharge before use.
replace
Healthy:46%
charge:80%
internal r=18.1mΩ
rated:500A
rePlAce
Battery is near end or at end of life, replace battery.
bad Cell, replace
Healthy:0%
charge:20%
internal r=45.2mΩ
rated:500A
BAd cell, rePlAce
Battery interior damaged, bad cell or short circuit, replace battery.
Charge, retest
Healthy:39%
charge:20%
internal r=30.1mΩ
rated:500A
cHArGe - retest
unstable battery, recharge, retest. if the same test result appear after recharge and retest, the battery is damaged, replace battery.
if a replace result is obtained remove the battery and retest the battery using the out of Vehicle mode before replacement.
if after testing the tester is in "in Vehicle" test state, press the enter key will bring up cranking test.
5.4.2. cranking test
select cranking test by scrolling menu and pressing enter Key. tester prompts as follows:
cranking test
start engine
start the engine as prompted the tester will automatically complete the cranking test and display result.
cranking test
rPm detected.
cranking voltage value lower than 9.6V is regarded as abnormal.
test results of the tester include actual cranking voltage and cracking time.
cranking test
times
cranking
10.13V
When cranking test is abnormal,the battery test result will also be displayed at the same time
© Jack sealey limited
490ccA
12.64V
440ccA
12.2V
490ccA
12.68V
0ccA
10.64V
310ccA
12.08V
780ms
normal
