good recharge
Healthy:78%
charge:30%
internal r=7.2mΩ
rated:500A
Good, recHArGe
Good battery but low current, recharge before use.
replace
Healthy:46%
charge:80%
internal r=18.1mΩ
rated:500A
rePlAce
Battery is near end or at end of life, replace battery.
bad Cell, replace
Healthy:0%
charge:20%
internal r=45.2mΩ
rated:500A
BAd cell, rePlAce
Battery interior damaged, bad cell or short circuit, replace battery.
Charge, retest
Healthy:39%
charge:20%
internal r=30.1mΩ
rated:500A
cHArGe - retest
unstable battery, recharge, retest. if the same test result appear after recharge and retest, the battery is damaged, replace battery.
5.4. battery in-vehicle
choose battery in vehicle and press enter key.
test in Vehicle
1. Battery test
2. cranking test
3. charging test
5.4.1. Battery test
When surface charge is detected by the tester it will prompt "surfAce cHArGe, turn liGHts on"
turn lights on to eliminate battery surface charge. tester will then display the following messages in sequence.
Battery test
1. check surface charge.
turn lights on.
2. turn head lights on for
about 10 seconds.
3. turn lights off.
the surface charge has now been eliminated. the tester will continue with test.
select battery type.
After the battery charger status has been selected, the tester will prompt to select battery type.
Battery type
1. regular flooded
2. AGm flat Plate.
3. AGm sprial
4. Gel
5. efB
Press Up/Down keys to select battery type then press enter key to confirm.
the battery tester will test each battery according to the selected system and rating.
Press Up/Down key to select according to the actual system standard and rating specified on the battery being tested.
select input
ccA
© Jack sealey limited
440ccA
12.2V
490ccA
12.68V
0ccA
10.64V
310ccA
12.08V
