Unitech MS840B Quick Start Manual

MS840B WITH CRADLE
The Unitech MS840B Wireless Scanner
Installation Instructions & Popular Configuration Settings
Begin Pairing
Step 3:
Cradle Mode
Cradle Mode
Scan here to begin pairing the MS840B using the cradle.
SETTINGS AND CONFIGURATION
The following section covers the most common
configuration settings for your MS840B scanner.
For additional configuration options please visit
unitechscanners.com/MS840B and select the
"Download" tab. You will find the User's Manual and a
variety of other resources.

Quick Start Guide

SETUP AND INSTALLATION
The following steps will walk you through the installation process.
Scan cradle barcode
Step 4:
Scan the barcode label that appears under the cradle. The scanner
will beep one time to indicate the pairing process has been succesful.
Your device is now ready to use.
Flash Mode
Flash Mode
Scan here to switch to Flash Mode from the default Trigger Mode. In
Flash mode, the MS840B will function automatically. It will scan at a set
interval.
Power On
Step 1:
Switch the power button to the on position.
Test & Finish
Open a word processing program such as Microsoft Word or
Notepad on your host. Now scan the following barcode:
If the word "Unitech" appears on the screen you have succesfully
installed your scanner. Congratulations!
Trigger Mode
Trigger Mode
Scan here to switch back to Trigger Mode. In Trigger Mode, the
MS840B will scan only when the scanner button is pressed.
Connect Cables & Charge
Step 2:
Plug the power supply cable into the MS840B cradle and into an electrical
outlet. Plug the interface cable into the MS840B cradle. Depending
on which type you have chosen, you must also connect it to the USB,
RS232, or PS/2 port on your computer. Charge for at least 5 hours.
Tab Mode
Tab Mode
You may wish to set your scanner to Tab Mode. In this mode, data will
tab over to the next column as you scan instead of jumping to the next
line. Scan the top barcode then the bottom barcode to switch to Tab
Mode from the default Enter Mode.
