Sony Xperia XZS SOV35 Settings Manual

Setting Guide
Introduction
Thank you for buying "Xperia™ XZs" (simply called the "product" from here on).
In this guide, settings and precautions for using the product are described.
* For detailed operations, refer to the "Basic Manual" (Japanese) app installed on the product or
"取扱説明書（詳細版） (Full Instruction Manual)" (Japanese) available on the au homepage.
● Basic operation ● Transferring data from au
Describes the basic operations.
Settings Menu
● Initial settings Import/export data to/from the
product using a microSD memory
When "ようこそ (Welcome)" appears
card or the au server.
after the product is powered on,
make initial settings.
● Setting the brightness of
● E-mail setting
the screen
Make the initial settings for @ezweb.
Adjusting the brightness is explained.
ne.jp etc.
● Setting the lighting time of
● Making a call
the backlight
Describes how to make a call.
Setting the lighting time is explained.
● Receiving a call
● Sending contacts
Describes how to receive a call.
Send contacts to another phone.
● Using "Basic Manual" app.
You can check the detail operation
method of the product.
Company names and product names referred to in this manual are trademarks or registered
trademarks of respective companies.
The TM, ® marks may be omitted in this manual.
Screen illustrations shown in this manual may look different from the actual screens.
In some cases, minor details or a part of a screen may be omitted.
April 2017, 1st Edition
Sold by: KDDI CORPORATION, OKINAWA
CELLULAR TELEPHONE COMPANY
Manufactured by: Sony Mobile Communications Inc.
1308-7595.1
● Wi-Fi ® network with is open network.
● Wi-Fi ®
network with is protected by security. To connect, enter a
password (security key).
● To add a Wi-Fi ® network manually, operate from [Add new network]
→Enter a network name (SSID) etc.→[SAVE]. Check the necessary
information for the connection in advance.
● To detect Wi-Fi ® networks manually or make the advanced settings
of Wi-Fi ® , after the initial settings, operate from the Home screen,
[ ]→[Settings]→[Wi-Fi]→[ ]→[Refresh], or operate from the Home
screen, [ ]→[Settings]→[Wi-Fi]→[ ].
®
Selecting from the detected Wi-Fi network and set.
When you select a protected Wi-Fi ® network, you need to enter a password (security
key).
1 2
Select Wi-Fi ® Enter a password (security
key)→[CONNECT]
network
■
STEP 5: Setting up a Google account
Set up a Google account so that you can synchronize with Gmail, contacts
of online service, calendar, etc. Setting for creating new Google account is
explained here.
●If you set up a Google account, you can use Google apps such as
"Gmail" or "Google Play".
●Gmail's mail address "(user name) @gmail.com" is automatically
created from the user name set with a Google account.
●Although you can use the product without setting a Google account,
some apps using Google account cannot be used. When you activate
the app, the setup screen for Google account appears.
Basic operation
OPower key/Screen lock key/
Status bar
Current status and Fingerprint sensor
notification icons
Power ON
are displayed.
Press and hold O for over 1 second.
Screen Lock
Press O while the screen is displayed. The
backlight turns off and screen lock is activated (to
avoid false operation of the keys or touch panel).
Unlocking Screen Lock
The lock screen appears when turning the
power on or turning on the backlight of the
screen by pressing O. Swipe (flick) the
screen up/left to cancel the screen lock.
Alternatively, while the lock screen is
displayed, touch O to unlock.
Apps key
Tap to display the apps screen.
n Task key
Tap to display the list of recently-used apps and
activate/exit the app. Also, the split screen is available.
h Home key
Tap to display the Home screen.
b Back key
Tap to return to the previous screen.
Display (Touch panel)
Operate directly touching with your finger.
■ Displaying menu
There are two types for displaying the screen menu; tapping " " and long
touching an input field or item.
1 2 3 4
[More options] *1 Enter "First name", Enter your Enter a user name
→[Create account] "Last name"→[NEXT] birthday and →[NEXT]
gender→[NEXT]
5 6 7 8
Enter a password Confirm the phone [I AGREE] [NEXT]
→[NEXT] number *3 →
[NEXT]→[VERIFY]
*1 If you have a Google account, enter the Gmail mail address or the phone number and tap
"NEXT", and then follow the onscreen instructions.
*2 Checking registration of username starts. If a username is unavailable, an entry screen for
prompting another user name appears.
*3 The phone number of your au IC card is entered automatically. When you enter another
phone number, enter the notified verification code and then tap "NEXT".
■ Opening the Notification panel
If any notification icons are displayed on
the left side of the status bar, slide down the
status bar to open the Notification panel. You Notification
panel
can check details of notification icons, start
corresponding apps, etc.
Slide the status bar down with two fingers or
slide the Notification panel down to display the
quick setting panel. You can set on/off of the
functions.
■ Touch panel operations
Tap/Double-tap Long-touch
Tap: Gently touch Keep touching an item
with your finger.
a screen and then
immediately release
your finger. Double-
tap: Touch the same
position twice.
Slide Swipe (flick)
While your finger is Operate the screen
gently touching the by quickly moving
screen, trace it to the (flicking) your finger
desired direction to up/down/left/right.
move over.
Pinch Drag
Touch the screen with Keep touching an item
two fingers and widen or icon, trace it to the
(pinch-out) or narrow desired direction to
(pinch-in) the fingers' move.
distance.
■ STEP 6: Setting the unlock method by
using fingerprint
Set whether to use the fingerprint authentication function. Tap "ADD
FINGERPRINT" and then follow the onscreen instructions. If you do
not register your fingerprint, [SKIP]→[SKIP ANYWAY].
●If you register your fingerprint or unlock method of the screen
lock, the setting screen of "Anything else?" appears after "STEP
10". Follow the onscreen instructions.
●Alternatively, after the initial settings, operate from the Home
screen, [ ]→[Settings]→[Lock screen & security]→[Fingerprint
*2 Manager] to set.
■ STEP 7: Setting Google services
Set the Google services such as backup etc. Confirm the settings
→[NEXT].
■ STEP 8: Setting Google apps
Setting the Google apps permission. [CONTINUE]→Confirm the
content of the app permission→[No thanks]/[YES I'M IN].
■ STEP 9: Setting Xperia™ services
Sign in for using Xperia™ services. Select the account and follow
the onscreen instructions. If you do not sign in, [Not now]→[SKIP].
■ STEP 10: Setting the Xperia Intelligence
engine™
Set the permission of Xperia Intelligence engine™ Tap "NEXT" and
then follow the onscreen instructions.
■ STEP 11: Setting the Accelerated Location
Set whether to allow collection of location data. Mark/Unmark the
"Location consent"→[NEXT].
■ STEP 12: Completion of setup
When the setup completion screen appears, tap "FINISH".
■ Setting app permission
When you first activate an app/function that access the functions or
information of the product, a confirmation screen for requesting access
permission appears.
If such confirmation screen appears, confirm the content and tap "DENY"/"ALLOW".
● If you do not permit, app/function may not be activated or use of function
may be restricted.
● For some apps/functions, an explanation screen for the permission may
appear. A confirmation screen may appear in several times and screen
content may vary. Confirm each content and follow the onscreen instructions.
●In this manual, description of the confirmation screen may be omitted.
■
Character entry
Use software keyboard to enter characters.
The software keyboard appears when you tap the entry field for registering
a contact, composing a mail, etc.
Software keyboard
With "SwiftKey Keyboard", you can use QWERTY keyboard to enter
characters, the numeric keypad to enter numbers and symbols, and the
symbol keypad for more symbols.
●Tap " " to display the numeric keypad. For the symbol keypad, tap " "
on the numeric keypad.
●Tap " " at the left edge of the candidate area to make advanced settings
for SwiftKey keyboard.
《QWERTY keyboard》 《Numeric keypad》 《Symbol keypad》
■ au Easy Setting
Set au convenient functions or services.
●By setting au ID, you can use various services provided by au such as auスマートパス (au Smart Pass) or "au Kantan Kessai", which allows you to purchase
apps from Google Play.
* au ID which is already used by another user cannot be set.
●Alternatively, after the initial setting is complete, from the Home screen, tap [
1 2 3 4
Select "Register au ID" [au IDの設定・ Enter a security
[Next]
→[Next] 保存 (Set/save code→[OK]
au ID)] * Default value is four-digit
number set at subscription.
8 9 10 11
Select "Turn Auto Select "Activate" or Select "Activate" or Select "Activate" or
Backup on" or "Skip activation"→ "Skip activation"→ "Skip activation"→
"Turn Auto Backup [Next] [Next] [Next]
off"→[Next]
* The screens of step from 8 to 12 appear only if "Agree" is selected in step 7.
* To complete the initial setting of Lookout for au, permit the access permission on the each request screen appeared after step 11.
Initial settings
When "ようこそ (Welcome)" appears after the product is powered on,
follow the onscreen instructions to set functions and services.
■ STEP START: Starting basic settings
Confirm the language and tap "開始する"/"GET STARTED".
●To change the language, tap "日本語 (Japanese)" to open the
language list, select "English (United States)", and tap "OK".
● When you tap "VISUAL AIDS", the setting of accessibility functions can be made.
●Alternatively, after the initial setting is complete, from the Home
screen, tap [ ]→[設定 (Settings)]→[言語と入力 (Languages &
input)]→[言語 (Languages)]→[言語を追加 (Add a language)] and
select "English"→"United States", and then drag the " " of "English
(United States)" up to the top of the language list.
■ STEP 1: Setting important information
Confirm applying the data communication charge and mark/unmark the
collection of anonymous data/statistical information→[ACCEPT].
● Alternatively, after the initial settings, operate from the Home screen,
[ ]→[Settings]→[About phone]→[Usage info settings] to set.
■ STEP 2: Selecting setup method
Tap "Set up as new".
● To use the data of the other Android phone etc. successively, tap
"Copy your data" and then follow the onscreen instruction.
■
STEP 3: Setting up the network connection
Tap "See all Wi-Fi networks"/"Use cellular network for setup".
● When you select "Use cellular network for setup", tap "CONTINUE" to
proceed to "STEP 5".
● When you tap "Don't use any network for setup", making the settings
of Google account etc. that the network connection is required cannot
be made. Tap "CONTINUE" and then follow the onscreen instructions.
■ STEP 4: Setting Wi-Fi ® connection
You can use a home wireless LAN (Wi-Fi ® ) or public wireless LAN to access the
Internet services. Operate in a place where signal of Wi-Fi ® network can be received.
]→[Settings]→[au Settings Menu]→[au Easy Setting].
5 6 7
Set password→ Select "Update" Confirm terms of
service→
[設定 (Set)]→ →[Next]
Select "Agree"→
[終了 (Exit)]
[Next]→[Agree]
12 13 14
Mark data to be Mark apps to [Finish]
restored→ install→
[次へ (Next)] [次へ (Next)]
