Dome DMMS1 User Manual

Thank you for purchasing the DOME
Motion Detector, which works with your Z-Wave
Certified Controller to monitor areas of your
home for movement and ambient light levels.
Figure 1 - Motion Detector Front
Motion Detector
Including/Connecting into the Z-Wave Network:
Follow the instructions for your Z-Wave certified
SENSOR LENS &
Controller to enter inclusion mode. LED Indicator
When prompted by the Controller:
1. For proper inclusion, bring the
Motion Detector to within 10 feet of your
Controller. After inclusion, the device can be
Figure 3 - Parts of the A. Sensor from the Front, B. Sensor from the
moved to any desired location.
2. Remove the cover of the Motion Detector by
Excluding/Disconnecting from the Z-Wave Network
twisting it apart.
Follow the instructions for your Z-Wave certified Controller
3. Remove the Battery Tab.
SolidWorks Student Edition.
For Academic Use Only. to enter exclusion mode. When prompted by the Controller:
4. Press the Connect Button quickly 3 times in
1. Remove the Cover and make sure the Motion Detector
a row.
is powered.
The LED Indicator will flash five times indicating 2. Press the Connect Button quickly 3 times in a row.
inclusion.
The LED Indicator will flash five times indicating exclusion/
disconnection.
Resetting the Motion Detector to Factory Settings:
CONNECT BUTTON
BATTERY COMPARTMENT
To disconnect from the Z-Wave Network and
SCREW HOLES
restore factory default settings:
1. Remove the Cover and make sure the
Motion Detector is powered.
A. B. C.
2. Hold the Connect Button for 10 seconds until
the LED Indicator blinks once, then release
Rear, and C. MOUNT (WALL MOUNT)
the button.
Only do this if the controller is disconnected or otherwise unreach-
able!
How to Use—Table Top:
You can use the facets on the Sensor Body to properly
angle the Motion Detector on a table top or bookshelf to
monitor a room.
1. Remove the Magnetic Cradle and store it for later use
if needed.
2. Make sure your device is powered on and that there
is enough Z-Wave coverage in your installation
location.
3. Follow Figure 4 and place the Sensor Body on a flat
horizontal surface with an unobstructed view of the
area you wish to monitor.
110 o
110.00°
Figure 2 - Using the Motion Detector on a Table Top
