Dome DMWS1 Manual

Thank you for purchasing the DOME
Leak Sensor, which works with your Z-Wave Cer-
tified Controller to monitor your home for leaks
and for rising water levels in your sump pump.
LED Indicator
Cradle
Lead
Figure 1 - Leak Sensor Front
Leak Sensor
Including/Connecting into the Z-Wave Network:
Follow the instructions for your Z-Wave certified Controller to
enter inclusion mode.
When prompted by the Controller:
1. For proper inclusion, bring the Leak Sensor to within 10 feet
of your Controller. After inclusion, the device can be moved
to any desired location.
2. Remove the cover of the Leak Sensor by twisting it apart
(Fig 3.)
3. Remove the Battery Tab.
4. Press the Connect Button quickly 3 times in a row.
Remote Sensor
The LED Indicator will flash five times indicating inclusion.
Twist Counter-Clockwise
to Open
Connect Button
Metal Feet
Battery Tab
Battery
Figure 2 - Opening the Leak Sensor
Excluding/Disconnecting from the Z-Wave Network:
Follow the instructions for your Z-Wave certified Controller to
enter exclusion mode.
When prompted by the Controller:
1. Remove the Cover of the Leak Sensor.
2. Press the Connect Button quickly 3 times in a row.
The LED Indicator will flash five times indicating exclusion/dis-
connection.
Resetting the Leak Sensor to Factory Default Settings:
To disconnect from the Z-Wave Network and restore factory default
settings:
1. Open the Back Plate and make sure the Leak Sensor is
powered.
2. Hold the Connect Button for 10 seconds until the LED Indicator
LED Indicator
blinks once, then release the button.
Only do this if the controller is disconnected or otherwise unreach-
able!
How to Use—Without Cradle: How to Use—With Cradle:
To use the cradle, place the sensor into the Cradle,
You can use the Leak Sensor to monitor most appli-
making sure the Metal Feet make full contact with the
ances and pipes for leaks without the cradle. Once
Metal Contacts. It can be placed on a surface or mount-
included in your Z-Wave system, place the Leak Sensor
ed on a wall using the included hardware. The Remote
on a flat surface near the item you want monitored
Sensor Probe plugs into the Cradle through the 3.5mm
where water will collect if it leaks. Make sure all three
minijack.
Metal Feet are touching the surface.
Metal Feet
Figure 4 - Showing the
Metal Feet
When water contacts the
Metal Feet, it will beep
and send an alert to your Leaking Water
Sensor
Z-Wave Controller notifying
Figure 3 - Using the Sensor
Without the Cradle
it of the detected water.
Figure 5 - The Cradle
