DSC programming for the Alexor and Impassa
THERE IS NO REASON TO BE IN ANY SECTION OF YOUR SYSTEM UNLESS IT IS
ON THIS QUICK START GUIDE. If you do not see it here, please question if you
Even though your Alexor/Impassa comes factory defaulted; you might want to default the system
just to make sure you have a clean slate to work with. To do this; follow the steps below:
You will have to enroll the keypad to do the following. To enroll the keypad press any button on the
keypad. You will then see a message that states that the keypad needs enrolled and then the keypad
will tell you to hold down the '1' & '*' keys. The keypad will enroll. Note: You must enroll the
keypad within 3 minutes of plugging in the main control panel.
To default the system you will enter into programming mode by typing:
*8 5555 on the keypad
•
You will then be asked for 'Section' .. Enter in 999
•
You will then be asked to enter Installer code .. Enter 5555
•
The keypad should beep and then ask you for 'Section' again .. Enter 999 again
•
You system will now be fully defaulted back to factory settings and your keypad will not
respond and will need enrolled again.
Here is a Sample Alarm Kit we will use for an example:
Description:
Front Door Sensor
Smoke Alarm
Bedroom Window Sensor
Living Room Motion
Before beginning you want to place the batteries in all the devices, except motions. Have
all devices laid in front of you in a nice order. You will put the batteries in the motion
sensors at the time you are ready to enroll them. With the door/window contacts, place the
transmitter and magnets side by side, as if they were mounted on a door or window (pay
attention to the arrows or lines on the side of the devices. These indicate where the devices
should line up with the magnets).
Created by:
Alarm System Store
should be doing it.
Type of Delay:
Delay (01)
24 hour Std, wireless (88)
Instant (03)
Interior Stay/Away (05)
Alarm System Store
http://alarmsystemstore.com
Zone #
01
02
03
04
http://alarmsystemstore.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Alexor and is the answer not in the manual?

Questions and answers

Related Manuals for DSC Alexor

Summary of Contents for DSC Alexor

  • Page 1 ON THIS QUICK START GUIDE. If you do not see it here, please question if you should be doing it. Even though your Alexor/Impassa comes factory defaulted; you might want to default the system just to make sure you have a clean slate to work with. To do this; follow the steps below: You will have to enroll the keypad to do the following.
  • Page 2 Created by: Alarm System Store http://alarmsystemstore.com Master Code by default is 1234 Installer Code by default is 5555 - (Do not ever lose this number, this is your only way into programming. If you change it, you better remember it.) You will always enter into programming by pressing *8 and the installer code (5555).
  • Page 3 Created by: Alarm System Store http://alarmsystemstore.com So for our sample kit we would enter everything in order of what we are working with. Enter *8-5555-001-01-88-03-05 and at the end of the zone definitions we will hit # # # to exit. Shutting Off Unused Zones (Program Section 202, 203, or 204) Since we are using only four (4) zones, we will need to shut off the remaining zones that are not being used.
  • Page 4 Created by: Alarm System Store http://alarmsystemstore.com FYI: Before exiting, if you are also programming a key fob, you will press and hold the arm and disarm buttons until the control panel asks you to verify the ESN Number. After confirming the ESN number by pressing (*), the display will then ask for a key fob number and you will just enter 01 for the first key fob and if you have another key fob that will be 02, the display panel will be ready to enroll another device.
  • Page 5 Making a DSC Alexor/Impassa call your phone You will want to enter programming by entering: * 8 5 5 5 5, enter program section 301 and then enter the telephone number for the system to call (Make sure the “D”...
