Phonak SmartLink+ Quick Reference Manual

Quick Reference Guide
A pupils radio aid system consists of
two parts:
• Transmitter (worn by teacher) and
• Receivers (worn by pupil)
For audio shoe advice visit
SmartLink+ transmitter
www.phonak.com/eschooldesk
3
4
5
1
2
6
7
8
A
B
C
Audio Shoes MLxi receiver
On/Off Button
Key
Phonak recommends
that you push the
Twin Microphone Ports
1
Middle "Zoom" button
On/Off & Mic Positions
2
down for 2 seconds to
Lavaliere Adjust Button turn off and on for
3
normal teaching.
Lavaliere Release
4
Clip
5
LCD Display
LCD Display
6
7 Bluetooth buttons
SmartLink+ Interface Port
8
Synchronising
To synchronise a receiver, turn the
Easylink+ on, or push the F button,
Hearing Instrument
within a 50cm range of the receiver.
Remote Controls
The receiver should beep to confirm
(NHS HI's are incompatible)
this action.
Change Channel
Press the + and F keys together.
SmartLink+ Interface
The channel indicator
Audio in
A
in the display
starts flashing.
Mic in
B
Press + or - to move
Charging Port
C
up/down channels.
Wearing & Adjustment
Integrated
6 inches
receiver
Channel Number
Battery Status
Mic Position
- Superzoom
- Zoom
- Omni (360°)
Standard 3.5mm audio cable
SmartLink+ Compatability
Smartlink+ is fully compatible with
ALL of Phonak's FM receivers, past
and present (examples shown).
Simply turn on the transmitter...
and start teaching!
For more information about your SmartLink+ and how to use other functions
please consult the user manual, or visit www.phonak.com/eschooldesk
Microphone Directionality
Smartlink+ has three microphone settings...
Superzoom
Narrow beam directionality for, in exceptional
circumstances, pointing at sound source, or
extremely harsh teaching environments.
1 Push!
Zoom (Recommended)
The recommended directional setting for
everyday teaching scenarios.
Omni-directional
2
Pull!
For using in quiet, group discussion situations
by placing at the opposite end of the table.
Charging
SmartLink+ interface
IF
should be attached to
charge the SmartLink+
or attach external
devices.
✓
OR
✓
