- Page 3 Main Features of ADAS CAM Verified ADAS Functions Which Were Adopted By Auto Makers As OEM Intelligent Lane Departure Warning Via Vehicle’s Turn Signal Connection! Front Collision Warning Even At Low Speed ! Easy But Professional Installation Mode ! Full HD Crystal Clear Image Quality ! Overheating Prevention Power System ! Specialized B2B Fleet Management Tools !
- Page 5 [Main Body & Functions] Internal GPS Touch DC power port Security Manaul (3.5 pi) Recording Button (REC) Menu Micro SD card Button socket Camera Volume Angle Adjustment Front Adjuster Button Camera (Full HD) Power Supply Extra Secondary Camera Connection Connection...
- Page 7 [ Basic Installation Guide ] This instruction shows how to install the main body and basic components .Please read carefully before installation. Clean installation If powered on , follow surface of windscreen the installation guide to (windshield) start setup. Remove tape off When setup gets bracket and install in completed , Live-view...
- Page 8 [Installation Mode] * Install Mode is to support easy setup for proper ADAS performance . * Install Mode appears when booting up for the first time. After Installation gets finished , it will not appear again. * If setup values are inputted differently via menu screen or manager program , the latest input values will be applied . * Check Power Connection It is the starting screen ②Check whether power...
- Page 9 * Check Indicator Lights Check turn signal wire <NO> connection, If both Left & Right arrows are turned on , Turn off indicating lights Press YES. and press OK If only 1 arrow is turned on , Press NO. If both lights are off –...
- Page 10 [Camera Settings] * Input Spec * Camera setting To perform ADAS To calibrate camera properly , input your angle correctly, make vehicle specifications, sure the vehicle is Press OK to continue parked on the flat ground , Press OK to continue Input the installed height Adjust the camera lens from the ground by...
- Page 12 [Screen Types & Explanation] Front Monitoring Live-view Mode ∙ shows the video is being recorded If a front vehicle is detected , HMW time will be indicated in Green . Center When warning signal is generated, TTC will turn Red. ( 0.7 as shown Number in the image ) A Red vehicle icon will appear when generating FCW signal...
- Page 13 ADAS Display Mode • In the front monitoring live view mode, touch the LCD screen to switch to ADAS Display Mode • Indications - LDW : When lane lines are detected , the lines in the display turn Green , the violated line will turn Red . - FCW : When a front vehicle is detected , the vehicle icon will appear.
-
Page 14: Menu Guide
Menu Guide [Basic Menu] User can enter into each functional setting in the basic menu screen. • The Basic Menu screen will appear when pressing the side M button or bottom home button of LCD. • Press each icon to enter into corresponding setting menu . - Page 15 [ADAS CAM] In ADAS Setup menu, it is possible to change settings of FCW and LDW. 1) Operating Settings Each function can be turned ON/OFF • Touch the button to switch between ON and OFF • 2) FCW Operating Speed : press the Left / Right arrow to change •...
- Page 17 [DVR] In DVR setup menu , it is possible to change recording operation and resolution. 4) Voltage Setup • It is recommended to measure the voltage level at the ACC On, and then input the prevention voltage value. * If prevention voltage value is below 12V, the vehicle battery could be discharged. [Play Movie] The recorded Video files in modes of Continuous/ Event / Parking can be checked instantly.
- Page 18 [Configuration] In Configuration menu , the operation settings can be configured . 1) Volume Control • Speaker Volume Adjustment : the speaker volume can be adjusted. (0~15) • MIC Volume Adjustment : the MIC input volume can be adjusted . (0~15) 2) Voice Alarm •...
- Page 19 [Configuration] System Setup sets LCD screen display and Screen OFF mode. • LCD setting : turns ON/OFF speed, speed unit, smart UI, and horizontal line • LCD display : on the display. language can be changed through Language Pack Update of •...
- Page 20 [Configuration] 4-3) Language • The default language is English, other language can be applied through the PC Manager. 4-4) System Info • User can check Version information of firmware and hardware • When Reset Setup button is pressed, the values stored in the system will be initialized, and the system will enter into Install Mode.
- Page 21 [Install] OPTIAN installation settings. If values entered through Install mode are arbitrarily modified, it may cause ADAS function errors. 1) Vehicle Type • Choose driver’s vehicle type. * If user selects a vehicle type, the values of Width and Height will be automatically set in 「Dimensions」...
- Page 22 [Vehicle Type Setting] 3) Dimension * To perform ADAS properly , input the actual vehicle width and installation height by using the arrow button. Camera * Measure the height from the ground Height the main body of camera Vehicle width * Blinker Active If the display arrow light blinks continuously even when turn indicators are off, change High/Low settings in the Dimensions...
-
Page 23: Optional Devices
OPTIONAL DEVICES [Cover Lock] The Cover Lock is designed to prevent theft and unauthorized setting changes. Bottom Keyhole Head Tape Cable Lock Position OPTIAN Open... - Page 24 [External Camera] An external/secondary camera can be attached to the rear / inside/ side of the car to record images. A 7m power cable is provided with the product. Cautions in mounting * Make sure to connect an external camera after turning off the power of the main body.
