Assembly
Assembly for Wet Vacuuming – Foam Filter
WARNING: Never use the vacuum without a filter. Check that the filter
is securely fitted at all times.
1. Remove the appliance head (2) from the tank (10) by unlocking the 2 x
side locking handles (6) pulling them outwards, then upwards (Fig A).
Place the appliance head (2) upside down onto a flat surface, or on its side
(if the carry handle is already assembled).
2. Remove the HEPA filter (16) (installed upon purchase) by pulling it away
from the appliance head (2) (Fig F).
3. Slip the foam filter (19) over the filter basket (14) (Fig.G). Ensure the foam
filter (19) covers the full filter basket (14) (Fig H).
NOTE: The foam filter (19) is only suitable for WET vacuuming.
IMPORTANT: Regularly clean the foam filter (19) and allow it to dry before
resuming vacuuming.
IMPORTANT: DO NOT use the HEPA filter for wet vacuuming (the HEPA
filter is pre-installed upon purchase).
IMPORTANT: The Wet and Dry Vacuum should only be connected
to a mains power supply socket; an RCD (Residual Current Device) is
recommended.
4. Re-assemble the appliance head (2) back onto the tank (10), and secure
the 2 x side locking handles (6).
F. G.
NOTE: Always unplug the appliance after use and before cleaning or
changing the filters or accessories.
14
e-mail: help@powertoolsupport.com
MODEL No.: MWW706S-35L-1200WC • 06/2018 • 61406
2400W Wet & Dry Vacuum
H.
AFTER SALES SUPPORT
1800 909 909
(toll free)
2400W Wet & Dry Vacuum

Fitting the Flexible Hose

Connect the flexible hose (17) to the flexible hose
outlet depending on the application required:
1. Vacuuming
Connect the flexible hose (17) to the flexible
hose outlet – suction (7) by inserting into the
outlet and aligning the arrow and locking pin
on the end of the flexible hose (17), with the
arrow and ridge on the top of the flexible hose
outlet – suction (7). This should ensure the
locking pin on the flexible hose (17) aligns
with the ridge in the flexible hose outlet –
suction (7). Rotate the flexible hose (17) to the
left to secure the hose into position (Fig I/J)
2. Blowing
Connect the flexible hose (17) to the flexible
hose outlet – blowing (8) by inserting into the
outlet and aligning the arrow and locking pin
on the end of the flexible hose (17), with the
ridge on the top of the flexible hose outlet –
blowing (8). This should ensure the locking pin
on the flexible hose (17) aligns with the ridge
in the flexible hose outlet – blowing (8). Rotate
the flexible hose (17) to the left to secure the
hose into position (Fig K/L)
AFTER SALES SUPPORT
1800 909 909
(toll free) MODEL No.: MWW706S-35L-1200WC • 06/2018 • 61406
Assembly
I.
J.
K.
L.
