Assembly

Fitting the extension tubes and tools

1. To fit an extension tube (18) to the end of the
flexible hose (17), apply the larger opening end
of an extension tube (18) over the end of the
flexible hose (17) (Fig M).
2. To add an additional (2 or 3) flexible tube/s,
apply the larger opening end of the extension
tube/s (18) over the first extension tube until
secure (Fig N).
3. For vacuuming, either the floor tool (20), or
crevice tool (21) can be added to the end of the
last extension tube (18) by simply pushing it
onto the extensions tube (Fig O/P)
O. P.
Operation
On/Off switch (Fig Q):
Switch Position 0: OFF (All operations shut off)
Switch Position I: For normal vacuuming
operation (wet or dry)
Switch Position II: Automatic Mode for Power
Tool operation. The vacuum motor will only turn
ON when a power tool, which is plugged into the
AC outlet socket (4) is switched ON. The vacuum
motor will turn OFF when the power tool is switched OFF.
16
e-mail: help@powertoolsupport.com
MODEL No.: MWW706S-35L-1200WC • 06/2018 • 61406
2400W Wet & Dry Vacuum
M.
N.
Q.
AFTER SALES SUPPORT
1800 909 909
(toll free)
2400W Wet & Dry Vacuum

Dry Vacuuming

WARNING: Users must strictly observe all
warnings and information contained in section
'General Safety Instructions' and in section
'Specific Safety Instructions' before operating this
appliance.
WARNING: DO NOT use the foam filter (19)
for dry vacuuming applications.
IMPORTANT: The Wet and Dry Vacuum should
only be connected to a mains power supply
socket; an RCD (Residual Current Device) is
recommended.
1. Ensure the tank (10) is completely dry and free
from dust and dirt.
2. Only use the HEPA filter (16) for dry vacuuming
applications (Fig R). Ensure you have already
fitted the flexible hose (17), extension
tubes (18), and if required, the floor tool
(20) or crevice tool (21) for dry vacuuming
applications.
IMPORTANT: Ensure the HEPA filter is securely
fitted before starting the Wet and Dry Vacuum.
3. Plug the power cord (9) into the mains power
outlet and turn on.
4. To commence vacuum mode operation, press
the "I" on the ON/OFF switch (3) (Fig S).
5. To turn off vacuum mode, press the "O" on the
ON/OFF switch (3) (Fig T).
* Dust bags (61406-DB) can also be used for dry
vacuuming and can be purchased separately as
an accessory. Refer to page 25 for details.
AFTER SALES SUPPORT
1800 909 909
(toll free) MODEL No.: MWW706S-35L-1200WC • 06/2018 • 61406
Operation
R.
S.
T.
17
