Part List

Parts List

1. Carry Handle
2. Appliance head
3. ON/OFF switch
4. AC outlet socket
5. On board storage / holders
6. Side Locking handle (x2)
7. Flexible Hose Outlet - Suction
8. Flexible Hose Outlet - Blower
9. Power cord
10. Tank
11. Drain Screw
1 2
14
16
5
8
9
10
e-mail: help@powertoolsupport.com
MODEL No.: MWW706S-35L-1200WC • 06/2018 • 61406
2400W Wet & Dry Vacuum
12. Base
13. Castor wheels (x4)
14. Filter basket
15. Floating Safety Valve
16. HEPA filter
17. Flexible Hose
18. Extension Tubes (x3)
19. Foam Filter
20. Floor Tool
21. Crevice Tool
14
15
19
AFTER SALES SUPPORT
1800 909 909
(toll free)
2400W Wet & Dry Vacuum
1
2
5
6
18
18
5
13
12
17
AFTER SALES SUPPORT
1800 909 909
(toll free) MODEL No.: MWW706S-35L-1200WC • 06/2018 • 61406
Part List
3
4
7
10
18
5
11
13
21 20
11
