ASF 2045 USER MANUAL
User Manual
Please read this manual carefully before using your meter.
The technical specifications and operating guides included in this manual are subject to changes without notice.
Please charge the battery before using your meter for the first time.
In case of any inquires after a period of usage, please contact the manufacturer.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Atlanta ASF 2045
Summary of Contents for Atlanta ASF 2045
- Page 1 ASF 2045 USER MANUAL User Manual Please read this manual carefully before using your meter. The technical specifications and operating guides included in this manual are subject to changes without notice. Please charge the battery before using your meter for the first time.
-
Page 2: Table Of Contents
User`s Manual Contents 1. DESCRIPTION ............................... 3 1.1 Introduction.............................. 3 1.2 Panel ................................ 3 2. BASIC FUNCTIONS .............................. 5 Turn on the equipment ............................. 5 2.1 Spectrum Analyzer ............................. 5 2.2 Constellation Analyzer ............................6 2.3 Satellite Finding ..............................8 2.4 Satellite Setting .............................. -
Page 3: Description
User`s Manual 1. DESCRIPTION 1.1 Introduction This meter is simple and convenient for setting and aligning a satellite dish. Using the parameters of satellite, you can set and align a satellite dish quickly, easily and accurately. IA601 can be used for satellite spectrum line scanning, and gain the field strength and quality data. Especially with video decode, both SD and HD channels, user can check the signal quality by video and audio performance directly. - Page 4 User`s Manual ○ 1 . RF IN: Satellite signal input port, connect directly to satellite antenna using coaxial cable. ○ 2 . LCD Screen: Show menus and video ○ 3 . LED LIGHTS: LCD Screen: Show menus and video. 22K: The LED turns on if 22k is available by antenna 13V: The LED turns on if 13 voltage outputs by antenna 18V: The LED turns on if 18 voltage outputs by antenna LOCK: The LED turns on if the signal locks...
-
Page 5: Basic Functions
User`s Manual 2. BASIC FUNCTIONS Turn on the equipment Turn on the power switch and then the device will enter to “Main Menu”. Press [EXIT] or [MENU] to enter video playing menu. Or press OK to enter submenu to analyzer or setting parameters. 2.1 Spectrum Analyzer 1. -
Page 6: Constellation Analyzer
User`s Manual Set DiSEqC type. Press [◄/►] button to switch between None/DiSEqC1.0/ DiSEqC1.1. Default set to None. Switch Type: Switch Input: Set DiSEqC 1.0 or DiSEqC 1.1’s input port. Default set to None. 5. Press [F3] to switch between Horizontal and Vertical polarity. 7. - Page 7 User`s Manual 3. Press [OK] on <Analyze by Frequency> option to set satellite and transponder for constellation, as shown in below: Satellite: Show and choose the satellite. Press [◄/►] to select satellite, or press [OK] to enter Satellite list. Press [◄/►] to select, the Symbol Rate and Pol will be changed correspondingly, press [OK] to enter transponder Frequency: list.
-
Page 8: Satellite Finding
User`s Manual 2.3 Satellite Finding 1. Press the [MENU] to display main menu. 2. Press [OK] on <Finding> option to enter satellite finding menu. Satellite: Show and choose the satellite. Press [◄/►] to select satellite, or press [OK] to enter Satellite list. Set LNB Type, press [◄/►] button to switch. -
Page 9: Satellite Setting
User`s Manual 2.4 Satellite Setting 1. Press the [MENU] to enter main menu 2. Press [OK] on <Satellite> option to enter Satellite setting menu. 3. Press [OK] on <Edit Satellite> item to enter satellite edit menu. Press [◄/►] button to switch between satellite list and transponder list. Edit satellites: Press [▲/▼] to navigate between satellites, and press [OK] to edit the Name, Longitude and Location information. - Page 10 User`s Manual Press [F3] to delete current selected satellite. A dialog will display on screen, user can confirm or cancel the delete operation. Press [SAT] to save all the modifications. Edit Transponders: Press [▲/▼] to navigate between transponders, and press [OK] to edit the current transponder. Press [F2] to add transponder.
- Page 11 User`s Manual Satellite: Show and choose the satellite. Press [◄/►] to select satellite, or press [OK] to enter Satellite list. LNB Type: Set LNB Type, press [◄/►] button to switch. Default set to UNIVERSAL. LO.LOW: Show the low local oscillator value. Use digital button to input the LO.LOW once the LNB Type is customized. LO.HIGH: Show the high local oscillator value.
-
Page 12: Angle Calculation
User`s Manual Press [▲/▼] to move cursor up or down. Longitude: Input the longitude directly by 0~9 numeric buttons. Press Location: Set the location. [◄/►] to switch between West/East. Latitude: Input the latitude directly by 0~9 numeric buttons. Press Hemisphere: Set the hemisphere. [◄/►] to switch between South/North. -
Page 13: Store Data View Menu
User`s Manual Satellite: Select the satellite you want to find by [◄/►] or press [OK] to enter the satellite list to select. Longitude: Input the longitude directly by 0~9 numeric buttons. Press Location: Set the location. [◄/►] to switch between West/East. Latitude: Input the latitude directly by 0~9 numeric buttons. -
Page 14: System Setting
User`s Manual 4. Press [▲/▼] to select the figures you want to display. 4. Press [◄/►] to turn pages for Data List. 5. Press [F3] to delete the selected records. 6. Press [OK] to enter the constellation/spectrum analyzing interface for current records. 2.7 System Setting 1. -
Page 15: Channel List
User`s Manual 3. Press [OK] on <Software Upgrade>, all the available files in plugged USB stick will be listed in a dialog, please choose the correct one to upgrade. 4. Press [OK] on <Import Satellites By USB>, all the available files in plugged USB stick will be listed in a dialog, please choose the correct one to import. -
Page 16: Channel Edit
User`s Manual 2. Press [▲/▼] to navigate between channels and press [OK] button to play your selected channel in video playing menu (whole screen mode). 3. Press [F1] to find channels by alphabet. 4. Press [SAT] to switch channel list between selected single satellite list and all channel list. 5. - Page 17 User`s Manual Move: press [F1] to sign the channel, press [▲/▼] to move to the position which you want to move to, and then press [OK] to confirm; Lock: press [F2] to lock or unlock the focused channel; Delete: press [F3] to delete or undelete the focused channel; Satellite switch: Press [SAT] to switch channel list between selected single satellite list and all channel list.
-
Page 18: Specifications
User`s Manual 3. Specifications Identification DVB-S2 DVB-S QPSK QPSK, 8QPSK Demodulation 1/2, 2/3, 3/4, 5/6, 1/4, 1/3, 2/5, 1/2, 3/5, 2/3, 3/4, 5/6, 8/9, 9/10, Code Rate 7/8, 2~90MSPS Symbol Rate 950-2150MHz Input frequency 75Ω Input Impedance 35dBuV（noise） Min.level in 90dBuV Max.level in Vertical 13V, Horizontal 18V, 350mA...
