Tramigo T23 Magnum Quick Start Manual

TIP:
HQ
T23 MAGNUM
Over 300,000 intersections, parks, public buildings and
other landmarks in your region are preloaded into your T23
CONFIGURATION
Magnum device. Use the "ADDPLACE" command to add HQ,
office, destination pier or other important locations.
General Settings
Most common use is Internet data (GPRS) communication enabling reporting to
server side, like Tramigo M1 Fleet Enterprise. Following commands are needed:
1) Register as Owner 4) Set the correct Mobile Operator
Owner Access Point Name APN, the default
is INTERNET
2) Name the T23 Magnum GPRS,APN,<APN>,<username-optional
Name,<name> >,<password-optional>
3) Optional: Add additional SMS user(s) 5) Set the IP address and Port name
and grant the access level GPRS,Connect,<ip address>,<port>,TCP
AddUser,<phone number>,
<Owner/Friend/Guest> 6) Boot the T23 Magnum after all
commands given
Boot,Hard
Mandatory: Enable power saving with command "SET,SLEEP,1" after you have completed all
planned configuration changes.
Note: If command ResetSettings is given to T23 Magnum, all preloaded settings are lost.
Configuration files and support is available at support@tramigo.com
Beacon Mode, Default
T23 Magnum has preloaded Beacon mode configuration. In this mode T23
Magnum is sending Location and Status report every 3 hours. It does not wake on
movement and responds received SMS and GPRS commands only during that
reporting time. Note: With command "LISTUSER" check the user number. For
GPRS data it is always #10. For SMS users it is #2 - #9.
You can change the 3 hours reporting interval, use following commands.
Changing the Location and Status reporting interval between 1-1440 minutes
Report,10,Find,<interval in minutes>
Report,10,Status, <interval in minutes>
Questions? Find us on Skype: Tramigosupport
or email us at support@tramigo.com
T23 MAGNUM CONFIGURATION
Active Mode
T23 Magnum wakes on scheduled reports and motion. This mode is used if
desired to have trip reports and motion alarms. Between scheduled reports and
trips theT23 Magnum goes to battery saving mode and as in a Beacon mode it
responds to received SMS and GPRS messages only when it is awake.
Enable motion wakeup
Set,WakeOnShock,1
Set,IgnitionInputShock,1
Location and Status reporting every 5 minutes, 2 kilometers or if
heading change more than 30 degrees, and every 720 minutes when
parked.
Report,10,Find,5,2,720,30
Report,10,Status,5,2,720,30
Battery Life Estimates
Configuration and Usage
Beacon mode. Waking to report every 3 hours, no
motion and trip reports.
Beacon mode. Waking to report every 12 hours, no
motion and trip reports.
Active mode. Waking on movement, reporting every 6
hours and generates trip reports. Traveling an average
of 1-2 hours per day.
Active mode. Waking on movement, reporting every 12
hours and generates trip reports. Traveling an average
of 1-2 hours per day.
Visit www.tramigo.com to check out the
free software for your T23 Magnum
5
English Version
Magnum
Battery Life
40 days
>40 days
20 days
Up to 30 days
Getting started with your T23 Magnum
Thank you for choosing Tramigo. This guide will help you get started with your T23 Magnum.
Copyright © 2014 Tramigo Ltd. Tramigo, M1 Move, T23, T23 Magnum, TLD, Tramigo
Landmarks and associated logos are trademarks of Tramigo Ltd. For more
infomation, visit our website at www.tramigo.com
6
T23 Magnum Quick Start Guide V1.0
For firmware V.1.0.9
