SMART-AVI AVRouter 8x8 Quick Start

TECHNICAL SPECIFICATIONS
Connector HD-15 socket
Format VGA, SVGA, XGA, RGBHV, RGsB, CVBS, YC, YUV, RGBS
Syncs TTL5VDC
Audio
Signal 15kHz 0db unbalanced 100 Ohms impedance
Connector RCA or 3.5mm stereo jack
Power
Voltage 90 – 230V, 5VDC 3A A/S 50/60Hz
Control
IR Optional IR control
TCP/IP Optional TCP/IP control
RS-232 RS-232 jacks
Dimensions
Height x Width x Depth 1.5U (5.24" x 19" x 11.25")
Weight 20lb
Video
In HD-15 female
Out HD-15 female
Audio
In 3.5mm stereo jack
Out 3.5mm stereo jack
ORDERING INFORMATION
AV08X08S Routes 8 UXGA/component to 8 remote monitors
Includes: [AV08X08, (PS5VDC 3A),CCRS23205MM,
(SM-CSW)]
AV08X08AS UXGA/audio routes 8 UXGA/audio to 8 remote monitors
Includes: [AV08X08A, (PS5VDC 3A), CCRS23205MM
(SM-CSW)]
2840 N. Naomi Ave.
Burbank, California 91504
Phone: (818) 565-0011
Facsimile: (818) 565-0020
7
Please visit smartavi.com for a expanded version of this manual.
smartavi.com
Quick Start
User Manual
AVRouter 8x8
Routes up to 8 XVGA and Stereo Audio Sources
to 8 Remote Location at Distances up to 100 feet Away
SmartAVI's AV Router 8x8 gives you the power to pull content from up to 8
separate computers and display it on up to 8 monitors individually or at the same
time. As you will soon find, this dynamic hardware/software solution makes
even the most "complicated" content delivery challenge a snap.
Whether you've purchased the A/V 8x8 for a retail, recording studio or even
mass-transit location, we encourage you to broaden your vision – explore your
creativity and use this dynamic piece of hardware to your fullest advantage.
This matrix switch is a powerful tool that you will now use to convey your own
message to clients, guests and/or employees the way you need it and want it to
be displayed.
