SMART-AVI HDMI4X4 User Manual

Technical Specifications
Video
Video Amplifier 1.65 gBPS
Bandwidth
Input Video Signal 1.2 volts
Input DDC Signal 5 volts
Single Link Range 1080p
HDMI Connector HDMI Type A 19 pin female
Control
2 front panel buttons
Power
Power Supply 5VDC-2A
Physical
Dimensions 12"W x 1.75"H x 7"D
Weight 4.05 lbs.
© Copyright 2008 Smart-AVI, All Rights Reserved
Notice
The information contained in this document is
subject to change without notice. Smart-AVI makes
no warranty of any kind with regard to this material,
including but not limited to, implied warranties
of merchantability and fitness for any particular
purpose.
Smart-AVI will not be liable for errors contained
herein or for incidental or consequential damages
in connection with the furnishing, performance or
use of this material.
No part of this document may be photocopied,
reproduced or translated into another language
without prior written consent from Smart-AVI.
For the complete manual, visit www.smartavi.com.
2840 N Naomi Ave.
Burbank, California 91504
Phone: (818) 565-0011
Facsimile: (818) 565-0020

User Manual

HDMI Router 4x4
Display content from any four computers
on any four screens independently.
www.smartavi.com
