Ametek ECLIPSE II Owner's Manual page 44

193111-095
TROUBLESHOOTING
SYMPTOM
Meter Reading Wrong
(Amps)
High Input Current
Display reads - Curve Error Fault
Display reads - Backup Timer
Fault
Display reads - Manual Stop Fault
Display reads - Low Current Fault
9-4
PROBABLE CAUSES
(1) Bad Output Connector
(2) Bad Harness/Connections – Loose Or Incorrect
(3) Internal Power Connection
(4) Bad Control Board
(5) Shunt Calibration needed
(1) Bad Internal Charger Primary Board
(2) AC Supply
(3) Bad Control Board
(4) Bad Harness/Connections – Loose Or Incorrect
(1) Bad Harness/Connections – Loose Or Incorrect
(2) Bad Control Board
(3) Bad Internal Charger Primary Board
(4) Charge Curve
(1) Fixed Temperature Set Incorrectly
(2) BID A.H. > Charger A.H.
(3) Bad Output Cable Connector
(4) Incorrect Charge Curve Setting
(5) Bad Battery
(6) Bad BID
(1) Someone Pressed Manual Stop Button
(2) Bad Connection (Keypad-Control)
(3) Bad Keypad
(4) Bad Control Board
(1) Fixed Temperature Set Incorrectly
(2) Bad Harness/Connections – Loose Or Incorrect
(3) Battery Not Fully Formed
(4) Bad Battery
(5) BID A.H. > Charger A.H.
(6) Bad Internal Power Connection
(7) AC Supply
(8) Bad AC Fuse
(9) Output Fuse Bad
(10) Bad Control Board
(11) Bad Internal Charger Primary Board
(12) Bad Heat Sink Thermostat, if equipped
ACTION
STEPS
13
3
41
4
44
5
1
4
3
3
4
5
25
27
26
13
25
32
28
45
6
7
4
27
3
46
32
26
41
1
2
11
4
5
19
September 30, 2011
