32. SPECIAL OPTION
Special option modes see below.
OFF
―P.T.S.― = Push to start mode.
The charger will not start until the ―ENTER‖ key is
pressed.
F.L.O. = Fault lockout mode.
The charger will not restart until any faults are reset
by pressing the ―ENTER‖ key with no battery
connected.
33. CYC. AMP HOURS
The ampere-hour setting of the charger during the
charge cycle. This value cannot exceed the maxi-
mum charger output rating.
34. CYCLE CELLS
The cell size setting of the charger during the charge
cycle. This value cannot exceed the maximum
charger output rating.
WARNING: Enabling the Finish Cell
Forming feature will cause the
charger to continue to run for a
period of time if the battery has
been disconnected before Charge
Complete or pressing the Manual
Stop key. This condition will
continue until the programmed
number of cycles have been
completed. The battery should
never be disconnected while a
charge is in progress.
35. FIXED CELL SIZE
The cell size the charger will operate at if the ‖multi-
cell mode‖ is not selected and the charger does not
detect a Prestolite BID module. See ―MULTI-CELL
MODE‖.
36. FIXED AMP HRS
The ampere-hour size the charger will operate at if
the charger does not detect a Prestolite BID module.
37. FIX.BAT.TEMP.
The battery temperature used for charger output volt-
age compensation, if the charger does not detect a
Prestolite BID Module (032 to 132°F).
CAUTION: Do Not Exceed the Battery
Manufacturer's Maximum allowed Battery
temperature.
September 30, 2011
EC2000 CONTROL FEATURES
38. BATTERY TYPE
The battery type the charger uses to select the proper
output voltage and current characteristic, if the
charger does not detect a Prestolite BID.
FLD = Standard flooded lead acid industrial type
battery curve.
CTM. = Custom curve. Uses the voltage and
current values programmed in the
STRT A/100 A.H.,FIN. A/100A.H., GAS. V/C.,
and LID. V/C.
YGR
SLR
DSG = Sealed lead acid battery curves
SLE
DAG
CDR
*MAH will be displayed if the Multi-Amp Hour
Feature is turned on.
39.
START AMPS/100
The selected output curve start current setting
(10.0 to16.3 amps per 100 ampere-hours).
40.
FINISH AMPS/100
The selected output curve finish current setting
(0.0 to 7.9 amps per 100 ampere-hours).
41. GASSING V/C
The selected output curve gassing voltage level
setting (2.00 to 2.99 volts/cell).
42. LID. V/C
The selected output curve lid voltage setting
(2.00 to 2.99 volts/cell).
43. CHARGER I.D.
The battery charger identification number.
Factory setting = 0000
44. REFRESH DELAY
The number of hours before the charger automati-
cally starts and refresh charges a battery that has
not been disconnected (8 to 99 hours).
Factory Setting = 72 hours.
45. DVDT DISABLE
Disables the automatic DV/DT charge termination
feature and enables Voltage Time charge
termination.
OFF = (DV/DT Mode)
ON = (VT mode)
193111-095
7-9
