Ametek ECLIPSE II Owner's Manual page 43

SYMPTOM
Battery Temperature
Too High
Incorrect Charge Rate
Doesn't Shutdown
When Battery Is
Disconnected
Erratic Operation
Meter Reading Wrong
(V/C)
September 30, 2011
PROBABLE CAUSES
(1) Insufficient Cool Down Before And/Or After Charging
(2) Battery Power Demand Too Great
(3) Rates Set Incorrectly
(4) Fixed Temperature Set Incorrectly
(5) Charge Curve Incorrect
(6) Equalize Schedule
(7) Control Set For Voltage/Time
(8) Control Set For Cell Forming
(9) Bad BID
(1) Rates Set Incorrectly
(2) Fixed Temperature Set Incorrectly
(3) Charge Curve Incorrect
(4) Battery A.H. Not Equal To Charger A.H.
(5) Battery Has Incorrect Size BID
(6) Bad Control Board
(7) BID Not Programmed Properly
(8) Inadequate Ventilation
(9) Charger Fans Not Operating
(1) Control Set For Forming Cycles
(2) Bad Control Board
(3) Bad Internal Charger Primary Board
(1) Bad Control Board
(2) Bad Harness/Connection - Loose or Incorrect
(3) Bad Power Connection
(4) Bad Output Cable Connector
(5) Moisture Inside Cabinet
(6) Lack of Maintenance
(7) High Ambient Temperature
(1) Bad Output Connector
(2) Bad Harness/Connection - Loose or Incorrect
(3) Internal Power Connection
(4) Bad Control Board
193111-095
TROUBLESHOOTING
ACTION
STEPS
39
40
26
27
25
24
36
35
28
26
27
25
26
28
4
28
15
18
35
4
5
4
3
41
13
42
43
16
13
3
41
4
9-3
