Specifications

Method
• Single Beam Absorption Infrared™
• Diffusion sample method (8001, 8001B, 8002, 8002B)
• Flow-Through sample method (70-120 ml/min) (8007, 8008)
Performance
Measurement Range
• 0-2000 ppm factory default
• Adjustable to 10,000 ppm with UIP software kit
Accuracy
±100 ppm or 7%, whichever is greater
Elevation (Pressure) Correction
Add 0.13% of reading per mm Hg decrease from 760 mm Hg (On-board
correction, user set with UIP software)
Response Time 0-90%
<1 minute
Warm-Up Time @ 25
<2 minutes

Operating Conditions

• 15 to 32°C (60 to 90°F)
• 0 – 95% RH, non-condensing
Storage Temperature
-40° to 70°C (-40 to 158°F)
Agency Certification
FCC Part 15 Class B, CE, California Energy Commission
Input/Output
Power
• 18-30 VAC RMS, 50/60 Hz – half-wave rectified
• 18-42 VDC polarity protected
• 1.75 VA maximum average power
• 2.75 VA peak power
Telaire Ventostat™ 8000 Series
o
C
Analog Output (Simultaneous)
• 0 - 10 VDC (100 Ohms output impedance)
• 4 - 20 mA (RLmax = 500 Ohms)
Relay Output
Normally Open and Normally Closed (wire either way), gold bifurcated,
2A max. @ 24VAC. Adjustable setpoint, factory set at 1000 ppm, 50
ppm hysteresis.
Wiring
18-28 AWG stranded copper wire only. 2 wires each for power, analog
output, relay
Digital I/O
RS-232 interface for use with optional PC software and cable in UIP kit
2072

Warranty Repairs

GE Sensing will repair Telaire product that fails to meet the terms
provided for in the Return and Warranty Policy Statement (See,
www.gesensing.com/service/brochures.htm).Warranty period shall start
from date of manufacture and be based on product category and type of
equipment as specified in Table 1: Product Warranty Periods. For all
warranty repairs, GE Sensing will bear all product repair parts, labor,
and standard ground shipping charges.
This product is covered by one or more of the following patents:
5,650,624/5,721,430/5,444,249/5,747,808/5,834,777/5,163,332/
5,340,986/5,502,308/6,344,798/6,023,069/5,370,114/5,601,079/
5,691,704/5,767,776/5,966,077/6,107,925/5,798,700/5,945,924/
5,592,147/6,255,653/6,250,133/6,285,290
USA
1100 Technology Park Drive
Billerica, MA 01821-4111
Telephone: 800-833-9438
978-437-1000
Fax: 502-479-6722
Web: www.gesensing.com
