2
2-Button Pendant Panic Sensor 868 GEN2
Installation Instructions
3.
Remove the old battery by sliding it from the holder and
install the new battery with the positive side up to observe
polarity (Figure 4). The red LED will blink when the
battery is installed with correct polarity.
Figure 4. Battery replacement
Circuit board
4.
Place the circuit board back into the housing, ensuring the
board is facing in the proper direction.
5.
Place the back cover on the housing and secure with the four
screws. Be sure the right and left activation buttons are in
the correct location (Figure 5).
Figure 5. Back cover activation buttons
Left button
LED
Battery
(positive side up)
Right button
Technical support
888 GE Security (888.437.3287). Toll-free in the US, Puerto Rico, and Canada.
503.885.5700 outside the toll-free area or contact your local dealer.
www.gesecurity.com
Lithium battery disposal
Expired lithium batteries are considered hazardous waste. Be
sure to dispose of old batteries according to battery directive
instructions and/or instructions from local government authori-
ties.

Specifications

Power source
3.0 V lithium battery
Typical standby current
3 uA
Operating temperature
10 to 120°F (-12 to 49°C)
Dimensions (L x W x D)
2.50 x 1.80 x 0.50 in. (64 x 46 x 13 mm)
RF frequency
868 MHz
Compatibility
GE Security control panels with 868 MHz
GEN2 receivers
Supervision rate
18 minutes
