Panasonic CS-XE12SKUA-1 Service Manual

Please file and use this supplement manual together with the service manual for Model No. CS-XE12SKUA/CU-XE12SKUA,
CS-XE15SKUA/CU-XE15SKUA, Order No. PAPAMY1601004CE, PAPAMY1608072AE.
This service information is designed for experienced repair technicians only and is not designed for use by the general public.
It does not contain warnings or cautions to advise non-technical individuals of potential dangers in attempting to service a product.
Products powered by electricity should be serviced or repaired only by experienced professional technicians. Any attempt to service
or repair the products dealt with in this service information by anyone else could result in serious injury or death.
There are special components used in this equipment which are important for safety. These parts are marked by
Diagrams, Circuit Board Diagrams, Exploded Views and Replacement Parts List. It is essential that these critical parts should be replaced
with manufacturer's specified parts to prevent shock, fire or other hazards. Do not modify the original design without permission of
manufacturer.
In order to avoid frostbite, be assured of no refrigerant leakage during the installation or repairing of refrigerant circuit.
CS-XE12SKUA-1
CS-XE15SKUA-1
A I R C O N D I T I O N E R
M O D E
A U T O
E C O N A V I C O M F O R T
O FF/O N O FF/O N
M O D E R F P
TEMP TEMP
POWERFUL/
A IR SW IN G
QUIET
FANSPEED
T I M E R T I M E R
O N O N S E T S E T
1 1 2 2 3 3
CANCEL
O F F O F F
AC RC
SET CHECK CHECK CLOCK RESET
WARNING
IMPORTANT SAFETY NOTICE
PRECAUTION OF LOW TEMPERATURE
Order No: PAPAMY1802092AE

Air Conditioner

Indoor Unit
CU-XE12SKUA-1
CU-XE15SKUA-1
© Panasonic Corporation 2018.
Outdoor Unit
Destination
U.S.A.
Canada
in the Schematic
!
