2. DemoShield provides several installation options to install ZDS II,
3. Follow the instructions on the screen to complete the installation.

Hardware Installation

The ZGP323 ICE features an Ethernet interface, a USB interface, and an
RS-232 serial port. Hardware installation consists of the following:
You have to reconfigure network settings on the PC or on the ZGP323
ICE before using the emulator.

Connecting Target Pod

Use an appropriate target pod and pin converter to connect the ZGP323
ICE to the target board.
panel connectors and
tion board included with the kit. The 20- and 28-PDIP target pods plug
into the associated PDIP sockets on the target board. For example, if your
target board has a 20-SOIC socket, mate the 20-PDIP target Pod onto the
20-PDIP to 20-SOIC converter. Then install the target pod and converter
assembly into the board's 20-SOIC socket
UM019606-0408
select Install ZDS II. You can install other software and accompany-
ing documentation later.
•
Connecting Target Pod
•
Connecting ZGP323 ICE to the Target Pod
•
Connecting ZGP323 ICE to OTP Programming Module (Optional)
•
Connecting ZGP323 ICE to a PC
Figure 1
Figure 2
Z8 GP™ ZGP323 In-Circuit Emulator
on page 4 illustrates the ZGP323 ICE top
on page 4 illustrates the ZGP323 evalua-
